PERFORMANCE |
Processor | Intel® Core Ultra 7 155H, 16C (6P + 8E + 2LPE) / 22T, Max Turbo up to 4.8GHz, 24MB |
AI PC Category | AI-Ready Workstations |
NPU | Integrated Intel® AI Boost, up to 11 TOPS |
Graphics | NVIDIA® RTX 2000 Ada Generation 8GB GDDR6 |
Chipset | Intel® SoC Platform |
Memory | 1x 32GB SO-DIMM DDR5-5600 Non-ECC |
Memory Slots | Two DDR5 SO-DIMM slots, dual-channel capable |
Max Memory | Up to 96GB (2x 48GB DDR5 SO-DIMM) |
Storage | 1TB SSD M.2 2280 PCIe® 4.0x4 Performance NVMe® Opal 2.0 |
Storage Slot | Two M.2 2280 PCIe® 4.0 x4 slots |
Max Storage Support | Up to two drives, 2x M.2 SSD • M.2 2280 SSD up to 4TB, 2TB each |
RAID Preset | None |
Card Reader | SD Express 7.0 Card Reader |
Audio Chip | High Definition (HD) Audio, Realtek® ALC3287 codec |
Speakers | Stereo speakers, 2W x2, Dolby Audio™ Premium |
Microphone | 2x, Array |
Camera | 5.0MP + IR with Privacy Shutter and Human Presence Detection |
Battery | 90Wh |
Power Adapter | 170W Slim Tip (3-pin) |
DESIGN |
Display | 16" WUXGA (1920x1200) IPS 300nits Anti-glare, 45% NTSC |
Touchscreen | None |
Color Calibration | None |
Pen | Pen Not Supported |
Keyboard | Backlit, English |
Dimensions (WxDxH) | 365 x 262 x 24.66 mm (14.37 x 10.32 x 0.97 inches) |
Weight | Starting at 2.22 kg (4.90 lbs) |
Case Color | Black |
Case Material | PC-ABS (Top), PC-ABS (Bottom) |
SOFTWARE |
Operating System | Windows® 11 Pro, English |
Bundled Software | None |
CONNECTIVITY |
WLAN + Bluetooth | Intel® Wi-Fi® 6E AX211, 802.11ax 2x2 + BT5.3 |
WWAN | Non-WWAN |
SIM Card | None |
Ethernet | 100/1000M (RJ-45) |
NFC | None |
Standard Ports | 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On 2x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with DisplayPort™ 2.1 1x HDMI® 2.1, up to 8K/60Hz 1x Headphone / microphone combo jack (3.5mm) 1x Ethernet (GbE RJ-45) 1x SD Express 7.0 card reader 1x Security keyhole |
Optional Ports (configured) | None |
Docking | Various docking solutions supported via Thunderbolt™ or USB-C®. For more compatible docking solutions, please visit Docking for ThinkPad® P16v Gen 2 |
SECURITY & PRIVACY |
Security Chip | Discrete TPM 2.0 Enabled |
Physical Locks | Kensington® Nano Security Slot, 2.5 x 6 mm |
Smart Card Reader | None |
Fingerprint Reader | Touch Style, Match-on-Chip, Integrated in Power Button |
Other Security | Camera privacy shutter (camera models) Ultrasonic Human Presence Detection for IR camera IR camera for Windows® Hello (facial recognition) |
MANAGEABILITY |
System Management | Non-vPro® |
ACCESSORIES |
Bundled Accessories | None |
CERTIFICATIONS |
ISV Certifications | Please visit ISV certifications for Lenovo® Workstations |
Green Certifications | ENERGY STAR® 9.0 EPEAT™ Gold Registered RoHS compliant TCO Certified 9.0 |
Mil-Spec Test | MIL-STD-810H military test passed |
