PERFORMANCE |
Processor | Intel Core™ Ultra 5 226V, 8C (4P + 4LPE) / 8T, Max Turbo up to 4.5GHz, 8MB Intel® Smart Cache |
AI PC Category | Copilot+ PC |
NPU | Integrated Intel® AI Boost, up to 40 TOPS |
Graphics | Integrated Intel® Arc™ Graphics 130V |
Chipset | Intel® SoC Platform |
Memory | 16GB Soldered LPDDR5X-8533, MoP Memory |
Memory Slots | Memory soldered to systemboard, no slots |
Max Memory | 16GB soldered LPDDR5X-8533 MoP, not upgradable |
Storage | 256GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0 |
Max Storage Support | One drive, up to 1TB M.2 2280 SSD |
Card Reader | No card reader |
Optical | None |
Audio Chip | High Definition (HD) Audio |
Speakers | 2Wx1 |
Power Supply | 65W 89% Adapter |
DESIGN |
Keyboard | USB, Calliope, Black, English (US) |
Mouse | USB Calliope Mouse, Black |
Expansion Slots | Two M.2 slots (one for WLAN, one for SSD) |
Case Color | Black |
Stand | None |
Adapter Cage | None |
Toolless Chassis Screw | None |
Mounting | None |
Pen | Pen Not Supported |
Form Factor | Tiny (1L) |
Dimensions (WxDxH) | Tiny only (without rubber feet) | 179 x 182.9 x 34.5 mm (7.05 x 7.2 x 1.36 inches) Tiny only (with rubber feet) | 179 x 182.9 x 36.5 mm (7.05 x 7.2 x 1.44 inches) |
Weight | Around 1.1 kg (2.43 lbs) |
CONNECTIVITY |
WLAN + Bluetooth | MediaTek Wi-Fi® 7 MT7925, 802.11be 2x2 + BT5.4 |
WWAN | WWAN Not Supported |
Ethernet | Integrated 100/1000M |
Front Ports | 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with data transfer and 5V@3A charging 1x USB-A (USB 10Gbps / USB 3.2 Gen 2), with Always On and 5V@2.1A charging 1x headphone / microphone combo jack (3.5mm) |
Rear Ports | 2x USB-A (Hi-Speed USB / USB 2.0), one supports Smart Power On 2x USB-A (USB 10Gbps / USB 3.2 Gen 2) 1x HDMI® 2.1 TMDS 1x DisplayPort™ 1.4b 1x Ethernet (GbE RJ-45) 1x Power connector |
Optional Rear Ports (configured) | DP 1.2 |
Monitor Cable | None |
SECURITY & PRIVACY |
Security Chip | Discrete TPM 2.0, TCG certified, FIPS 140-2 certified |
Physical Locks | Kensington Security Slotâ„¢, 3 x 7 mm |
Chassis Intrusion Switch | Chassis Intrusion Switch |
CERTIFICATIONS |
Green Certifications | ENERGY STAR® 9.0 RoHS compliant TCO Certified, generation 10 |
SOFTWARE |
Operating System | Windows® 11 Pro, English |
Bundled Software | None |
