Processor

Intel Core™ i5-14400, 10C (6P + 4E) / 16T, P-core 2.5 / 4.7GHz, E-core 1.8 / 3.5GHz, 20MB Intel^® Smart Cache

Graphics

Integrated Intel^® UHD Graphics 730

Chipset

Intel^® Q670 Chipset

Memory

2x 8GB UDIMM DDR5-4800

Memory Slots

Two DDR5 UDIMM slots, dual-channel capable

Max Memory

Up to 64GB DDR5

Storage

512GB SSD M.2 2280 PCIe^® 4.0x4 NVMe^® Opal 2.0

Max Storage Support

Up to three drives, 1x 3.5" HDD + 1x 2.5" HDD + 1x M.2 SSD • 3.5" HDD up to 2TB • 2.5" HDD bay is only for customer self upgrade • M.2 SSD up to 2TB each

Card Reader

No Card Reader

Optical

None

Audio Chip

High Definition (HD) Audio, Realtek^® ALC623-CG codec

Speakers

1Wx1

Power Supply

260W 90%

DESIGN

Keyboard

USB Traditional Keyboard, Black, English

Mouse

USB Calliope Mouse, Black

Optional Bay

None

Expansion Slots

One PCIe^® 3.0 x16, low-profile, length ≤ 155mm, height ≤ 70mm

One PCIe^® 3.0 x1, low-profile, length ≤ 155mm, height ≤ 70mm

Two M.2 slots (one for WLAN, one for SSD)

Case Color

Black

Stand

None

Dust Filter

None

Pen

Pen Not Supported

Form Factor

SFF (8.2L)

Dimensions (WxDxH)

92.5 x 297.7 x 339.5 mm (3.6 x 11.7 x 13.4 inches)

Weight

Around 5.3 kg (11.7 lbs)

CONNECTIVITY

WLAN + Bluetooth

Intel^® Wi-Fi^® 6 AX201, 802.11ax 2x2 + BT5.2

WWAN

WWAN Not Supported

Ethernet

Integrated 100/1000M

Front Ports

1x USB-C^® (USB 5Gbps / USB 3.2 Gen 1), with 15W charging

4x USB-A (USB 5Gbps / USB 3.2 Gen 1)

1x headphone / microphone combo jack (3.5mm)

1x microphone (3.5mm)

Rear Ports

4x USB-A (Hi-Speed USB / USB 2.0)

1x HDMI^® 2.1 TMDS

1x DisplayPort™ 1.4a (HBR2, DSC)

1x Ethernet (RJ-45)

Optional Rear Ports (configured)

None

SECURITY & PRIVACY

Security Chip

Discrete TPM 2.0, TCG certified, FIPS 140-2 certified

Fingerprint Reader

No fingerprint reader

Physical Locks

Kensington Security Slot™, 3 x 7 mm

Padlock Loop

Smart Cable Clip

None

Chassis E-Lock

None

Chassis Intrusion Switch

None

MANAGEABILITY

System Management

Non-vPro^®

CERTIFICATIONS

Green Certifications

ENERGY STAR^® 8.0

EPEAT™ Gold Registered

ErP Lot 3

GREENGUARD^®

RoHS compliant

TCO Certified, generation 9

Mil-Spec Test

MIL-STD-810H military test passed (Low Pressure [Altitude], High Temperature, Low   Temperature, Temperature Shock, Humidity, Sand and Dust, Vibration, Shock, Solar Radiation, Contamination by Fluids, Salt Fog)

SOFTWARE

Operating System

Windows^® 11 Pro, English

Bundled Software

None

ACCESSORIES

Bundled Accessories

None
