PERFORMANCE |
Processor | AMD Ryzen™ 7 250 (8C / 16T, 3.3 / 5.1GHz, 8MB L2 / 16MB L3) |
AI PC Category | AI PC |
NPU | Integrated AMD Ryzen™ AI, up to 16 TOPS |
Graphics | Integrated AMD Radeon™ 780M Graphics |
Chipset | AMD SoC Platform |
Memory | 1x 16GB SODIMM DDR5-5600 |
Memory Slots | Two DDR5 SODIMM slots, dual-channel capable |
Max Memory | Up to 64GB DDR5-5600 |
Storage | 512GB SSD M.2 2242 PCIe® 4.0x4 NVMe® |
Storage Slot | Two M.2 slots • One M.2 2242 PCIe® 4.0 x4 slot • One M.2 2280 PCIe® 4.0 x4 slot |
Max Storage Support | Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 2TB • M.2 2280 SSD up to 2TB |
Card Reader | SD Card Reader |
Audio Chip | High Definition (HD) Audio, Realtek® ALC3287 codec |
Speakers | Stereo speakers, 2W x2, Dolby Audio™ |
Microphone | 2x, Array |
Camera | FHD 1080p + IR Hybrid with Privacy Shutter |
Battery | 48Wh |
Power Adapter | 65W USB-C® (3-pin) |
Special Features | Modern Standby |
DESIGN |
Display | 16" WUXGA (1920x1200) IPS 400nits Anti-glare, 45% NTSC, 60Hz |
Touchscreen | None |
Screen-to-Body Ratio | 90% |
Color Calibration | No Color Calibration |
Pen | Pen Not Supported |
Keyboard | Backlit, English |
Touchpad | Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches) |
Dimensions (WxDxH) | 356 x 253.5 x 17.5 mm (14.01 x 9.98 x 0.69 inches) |
Weight | Starting at 1.7 kg (3.75 lbs) |
Case Color | Arctic Grey |
Case Material | Aluminium (Top), PC-ABS (Bottom) |
Surface Treatment | Anodizing Sandblasting (Top), Texture (Bottom) |
SOFTWARE |
Operating System | Windows® 11 Pro, English (US) / English (UK) |
Bundled Software | Office Trial |
CONNECTIVITY |
WLAN + Bluetooth | Wi-Fi® 6, 802.11ax 2x2 + BT5.2 |
WWAN | WWAN Not Supported |
Ethernet | 100/1000M (RJ-45) |
Standard Ports | 1x USB-A (USB 5Gbps), Always On 1x USB-A (USB 5Gbps) 2x USB-C® (USB4® 40Gbps), with USB PD 45-65W and DisplayPort™ 1.4a 1x HDMI® 2.1, up to 4K/60Hz 1x Headphone / microphone combo jack (3.5mm) 1x Ethernet (RJ-45) 1x SD card reader |
Docking | Various docking solutions supported via USB-C®. For more compatible docking solutions, please visit Docking for ThinkBook® 16 G9 AHP |
SECURITY & PRIVACY |
Security Chip | Discrete TPM 2.0 Enabled |
Physical Locks | Kensington Nano Security Slot™, 2.5 x 6 mm |
Fingerprint Reader | Touch Style, Match-on-Chip, Integrated in Power Button |
Other Security | Camera privacy shutter IR camera for Windows® Hello (facial recognition) |
ACCESSORIES |
Bundled Accessories | None |
CERTIFICATIONS |
Green Certifications | ENERGY STAR® 9.0 EPEAT™ Gold Registered ErP Lot 6/26 RoHS compliant TCO Certified, generation 10 |
Mil-Spec Test | MIL-STD-810H military test passed |
Other Certifications | TÜV Rheinland® Low Blue Light (Software Solution) |
