ESSENTIALS |
|
Product Collection | Intel® Core™ Ultra Processors (Series 2) |
Code Name | Products formerly Arrow Lake |
Vertical Segment | Desktop |
Processor Number | 235 |
Overall Peak TOPS (Int8) | 27 |
CPU SPECIFICATIONS |
|
Total Cores | 14 |
# of Performance-cores | 6 |
# of Efficient-cores | 8 |
# of Low Power Efficient-cores | 0 |
Total Threads | 14 |
Max Turbo Frequency | 5 GHz |
Performance-core Max Turbo Frequency | 5 GHz |
Efficient-core Max Turbo Frequency | 4.4 GHz |
Performance-core Base Frequency | 3.4 GHz |
Efficient-core Base Frequency | 2.9 GHz |
Cache | 24 MB Intel® Smart Cache |
Total L2 Cache | 26 MB |
Processor Base Power | 65 W |
Maximum Turbo Power | 121 W |
Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
AI Software Frameworks Supported by CPU | OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN |
CPU Lithography | TSMC N3B |
SUPPLEMENTAL INFORMATION |
|
Embedded Options Available | No |
Use Conditions | PC/Client/Tablet, Workstation |
MEMORY SPECIFICATIONS |
|
Max Memory Size (dependent on memory type) | 256 GB |
Memory Types | Up to DDR5 6400 MT/s |
Max # of Memory Channels | 2 |
ECC Memory Supported | Yes |
GPU SPECIFICATIONS |
|
GPU Name | Intel® Graphics |
Graphics Base Frequency | 300 MHz |
Graphics Max Dynamic Frequency | 2 GHz |
GPU Peak TOPS (Int8) | 6 |
Graphics Output | eDP1.4b, DP 2.1 UHBR20, HDMI 2.1 FRL |
Xe-cores | 3 |
Max Resolution (HDMI) | 4096 x 2304 @ 60Hz (HDMI 2.1 TMDS) 7680 x 4320 @ 60Hz (HDMI 2.1 FRL) |
Max Resolution (DP) | 7680 x 4320 @ 60Hz |
Max Resolution (eDP - Integrated Flat Panel) | 3840 x 2400 @ 120Hz |
DirectX* Support | 12 |
OpenGL* Support | 4.5 |
OpenCL* Support | 3 |
H.264 Hardware Encode/Decode | Yes |
H.265 (HEVC) Hardware Encode/Decode | Yes |
AV1 Encode/Decode | Yes |
Intel® Quick Sync Video | Yes |
# of Displays Supported | 4 |
Device ID | 0x7D67 |
Intel® Deep Learning Boost (Intel® DL Boost) on GPU | Yes |
AI Software Frameworks Supported by GPU | OpenVINO™, WindowsML, DirectML, ONNX RT, WebGPU |
NPU SPECIFICATIONS |
|
NPU Name | Intel® AI Boost |
NPU Peak TOPS (Int8) | 13 |
Sparsity Support | Yes |
Windows Studio Effects Support | Yes |
AI Software Frameworks Supported by NPU | OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN |
EXPANSION OPTIONS |
|
Direct Media Interface (DMI) Revision | 4 |
Max # of DMI Lanes | 8 |
Intel® Thunderbolt™ 4 | Yes |
Scalability | 1S Only |
PCI Express Revision | 5.0 and 4.0 |
PCI Express Configurations | Up to 1x16+2x4, 2x8+2x4, 1x8+4x4 |
Max # of PCI Express Lanes | 24 |
PACKAGE SPECIFICATIONS |
|
Sockets Supported | FCLGA1851 |
Thermal Solution Specification | PCG 2022C |
Max Operating Temperature | 105 °C |
Package Size | 45 mm x 37.5 mm |
ADVANCED TECHNOLOGIES |
|
Intel® Gaussian & Neural Accelerator | 3.5 |
Intel® Thread Director | Yes |
Intel® Speed Shift Technology | Yes |
Intel® Turbo Boost Technology | 2.0 |
Intel® Hyper-Threading Technology | No |
Intel® 64 | Yes |
Instruction Set | 64-bit |
Instruction Set Extensions | Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 |
Idle States | Yes |
Enhanced Intel SpeedStep® Technology | Yes |
Thermal Monitoring Technologies | Yes |
Intel® Volume Management Device (VMD) | Yes |
SECURITY & RELIABILITY |
|
Intel vPro® Eligibility | Intel vPro® Enterprise |
Intel® Threat Detection Technology (TDT) | Yes |
Intel® Active Management Technology (AMT) | Yes |
Intel® Standard Manageability (ISM) | Yes |
Intel® Remote Platform Erase (RPE) | Yes |
Intel® One-Click Recovery | Yes |
Intel® Secure Key | Yes |
Intel® Control-Flow Enforcement Technology | Yes |
Intel® Total Memory Encryption - Multi Key | Yes |
Intel® AES New Instructions | Yes |
Intel® Trusted Execution Technology | Yes |
Execute Disable Bit | Yes |
Intel® OS Guard | Yes |
Intel® Boot Guard | Yes |
Mode-based Execute Control (MBEC) | Yes |
Intel® Stable IT Platform Program (SIPP) | Yes |
Intel® Virtualization Technology with Redirect Protection (VT-rp) | Yes |
Intel® Virtualization Technology (VT-x) | Yes |
Intel® Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel® VT-x with Extended Page Tables (EPT) | Yes |
