Socket

Soldered-down BGA

Internal Drive Form Factor

M.2 SSD

# of Internal Drives Supported

1

TDP

15 W

DC Input Voltage Supported

19VDC

Processor Included

Intel® Pentium® Silver N6005 Processor (4M Cache, up to 3.30 GHz)

Total Cores

4

Total Threads

4

Processor Base Frequency

2.00 GHz

Lithography

10 nm

Memory Types

DDR4-2933 1.2V SO-DIMM

Max # of Memory Channels

2

Max # of DIMMs

2

ECC Memory Supported

No

Integrated Graphics

Yes

Graphics Output

DP++/HDMI

# of Displays Supported

2

PCI Express Revision

Gen 3

M.2 Card Slot (wireless)

1

M.2 Card Slot (storage)

1

# of USB Ports

6

USB Configuration

2x front USB 3.2 Gen 1 and 2x rear USB 3.2 Gen 2; 2x USB 2.0

USB Revision

3.2 Gen 2 / 3.2 Gen 1 / 2.0

Audio (back channel + front channel)

1x 3.5mm stereo out jack, 1x 3.5mm microphone jack

Integrated LAN

10/100/1000

Integrated Wireless

Intel® Wireless-AC 9462 + Bluetooth 5.0

Integrated Bluetooth

Yes

Chassis Dimensions

135x115x36mm

Intel® HD Audio Technology

Yes

Intel® Platform Trust Technology (Intel® PTT)

Yes

Intel® AES New Instructions

Yes
