AUDIO

Number of Microphones

8

Microphone Type

MEMS

Frequency Response

20Hz ~ 20kHz

Voice Pickup Sampling Rate

48kHz

Voice Pickup Range

5 meters (16.4 ft)

Power Rating

5W

Maximum Output Sound Pressure Level

91 dB SPL @ 0.5m/1W

AUDIO ALGORITHM

Full-duplex Audio

Yes

Automatic Noise Suppression (ANS)

AI noise-cancelling, eliminates 300+ common noises

Automatic Gain Control (AGC)

AI AGC

Automatic Echo Cancellation (AEC)

AI AEC

Dereverberation

AI-powered

Beamforming

Omnidirectional, cardioid, super cardioid, figure-of-eight, stereo

Audio Modes

Noise reduction, original sound

HARDWARE

Processor

AI Chip

Storage

4+32GB

Battery Capacity

9800mAh

Input Power

9V/2.2A, 5V/3A

Charging Time

5 hours

Battery Life (talk time)

Up to 12 hours

Screen Size

1.82-inch customized touchscreen

Connection Method

Dongle, Bluetooth, USB

Device Cascade

Supports wireless linking of 3 devices *Feature available via future OTA update.

Dimensions

Ø64.3mm (2.53in) Raised: 248mm (9.76in), Collapsed: 198mm (7.80in)

Weight

490g (17.3 oz)

Operating Temperature

32°F - 104°F (0 - 40°C) *Tested in a lab environment.

Colors

Arctic White

SYSTEM REQUIREMENTS

Computer

Windows 10 or later, MacOS 12 or later.

Mobile phone/Tablet

Android 10 or later, iOS 12 or later, iPad OS 12 or later.

INSTA360 LINK 2 PRO

Sensor Size

1/1.3"

Video Resolution

Landscape:

4K@30/25/24fps

1080p@60/50/30/25/24fps

720p@60/50/30/25/24fps

360p@30/25/24fps

Portrait:

4K@30/25/24fps

1080p@60/50/30/25/24fps

720p@60/50/30/25/24fps

Video Coding Format

H.264, MJPEG

(4K and 1080p60fps Portrait mode do not support H.264)

Exposure Compensation

±3 EV

ISO

Dual Native ISO

100~3200

Shutter Speed

1/8000–1/30s

White Balance

2000–10000K

Aperture

F/1.9

35mm Equivalent Focal Length

24 mm

Fixed FOV

83.9º DFOV, 71.4º HFOV

Digital Zoom

Up to 4x

Autofocus

Supported (Focus distance: 12cm–∞)

HDR

Supported

Microphones

2

Noise Reduction

AI Noise-Canceling

Audio Modes

Standard, Wide, Focus, Original

Modes

AI Tracking, Smart Whiteboard, DeskView, Virtual Background

GIMBAL

Gimbal

2-Axis

HARDWARE

Button

1x Touch Key

Connectivity

USB-C Cable (USB 2.0) or USB-C to USB-A adapter

Power Consumption

5V/1A

Mounting Options

Magnetic Mount with 1/4" mounting point for external tripod

Dimensions (W x H x D)

71.3×58.9×38mm (2.8×2.3×1.5in)

Weight

Without Magnetic Mount: 102.5g (3.6oz)

With Magnetic Mount: 167.5g (5.9oz)

Operating Temperature

32°F to 104°F (0°C to 40℃)

*Tested in a lab environment.

Color

Graphite Black

SYSTEM REQUIREMENTS

CPU

i5-5 generation or later (advanced features require i5-10 generation or later)

RAM

8GB or above (advanced features require 16GB or above)

Link Controller

Windows: Windows 10 or later. Does not support ARM-based Windows.

Mac: macOS 11.0 or later. Virtual Camera requires macOS 13.0 or later.

Background Blur & Background Replacer

Windows: Supports all NVIDIA GPUs. AMD GPUs may experience compatibility issues; please contact the Insta360 Customer Service team before purchasing. Verified AMD GPUs include Radeon (TM), RX Vega 10, 780M, RX 560, RX 6600 and RX 6750 GRE.

Mac: macOS 13.0 or later.

Green Screen

Windows (NVIDIA GTX 1050 Ti & above): Up to 4K

Windows (NVIDIA below 1050 Ti): Not supported Windows (Non-NVIDIA GPUs): Up to 4K

macOS (Apple Silicon): Up to 4K

macOS (Intel): Up to 1080p

Natural Bokeh

Windows:

NVIDIA GTX 1080 or later, RTX 2060 or later GPUs. Does not support AMD GPUs.

Resolution support (depends on GPU capability):

Desktop GPUs:

Compute capability 8.6 or higher: Supports 4K and below

Compute capability below 7.5: Supports 1080p and below

Laptop GPUs:

Compute capability 8.9 or higher: Supports 4K and below

Compute capability below 8.6: Supports 1080p and below

For GPU specs, visit NVIDIA’s official page.

Mac:

M1 chip or later. Does not support Intel chips.

*Insta360 Virtual Camera is automatically installed with Link Controller. Virtual Camera supports Smart Whiteboard Mode, Natural Bokeh, Background Blur, Background Replacer, Beautify and Makeup. Virtual Camera does not support 50fps or 60fps. 4K resolution for Beautify and Makeup is currently only supported on macOS (Apple M1 or later and Intel i5 or later).
