GENERAL |
|
Polar Pattern | Omnidirectional |
Selectable Pickup Modes | Omnidirectional/Super-directional/Cardioid/Figure-8 |
Frequency Response | Low Cut Off: 20Hz-20kHz Low Cut On: 100Hz-20kHz |
Microphone Sensitivity | Microphone Capsule: -38±1 dBV@1kHz, 94dB SPL |
Signal-to-Noise Ratio (SNR) | 72dB (A-weighted) |
Maximum Sound Pressure Level (SPL) | 130 dB SPL@10% THD |
Sampling Frequency | 48kHz |
Bit Depth | 32-bit float/24-bit *32-bit float only applies to Transmitter's internal recordings. |
Maximum Input Level (3.5 mm) | -8dBV |
Equivalent Noise | 22dB (A-weighted) |
Monitor Interface Output Power | Max Output Power: 20 mW@1 kHz，32 Ω |
Max Transmission Range | 400m *400 meters is measured when the Transmitter is connected to the Receiver in an open, unobstructed, and interference-free environment. When the Transmitter is connected to Insta360 X5 via Bluetooth in an open, unobstructed, and interference-free environment, the transmission range is about 100 meters, which may be affected by device orientation, camera shooting modes, and other factors. |
TRANSMITTER |
|
Dimensions | 38 × 12.2mm (Diameter×H) |
Weight | 19.7g (Without Clip) |
Display | 6-Color E-Ink Screen Size: 1.22'' Resolution: 240 × 208 PPI: 197 (Pixels Per Inch) |
Wireless Mode | GFSK 1Mbps and 2Mbps |
Equivalent Isotropic Radiated Power (EIRP) | 2.400-2.4835GHz: ≤ 20dBm (FCC/CE/SRRC/MIC) |
Wireless Mode Operating Frequency | 2.400-2.4835GHz |
Bluetooth Protocol | Bluetooth V5.4 |
Bluetooth Operating Frequency | 2.400-2.4835GHz |
Bluetooth Transmitter Power (EIRP) | BLE: ≤ 20 dBm BR/EDR: ≤ 20 dBm |
Battery Type | Li-ion |
Battery Capacity | 240mAh |
Battery Energy | 0.94Wh |
Battery Voltage | 3.89V |
Charging Specification | Max 5V |
Charging Temperature | 0℃ to 45℃ |
Operating Temperature | -10℃ to 45℃ |
Charging Time | Fully charged in approximately 1 hour, 80% in about 24 minutes. *Tested in a lab environment with a 5V/3A charger. |
5-Minute Fast Charge | A 5-minute charge gives 1.5 hours of use. *Tested in a lab environment with the Transmitter’s battery below 50%, charged with a 5V/3A charger. Noise cancellation and internal recording on Transmitter are off. Close-range recording in an interference-free environment, with the Transmitter connected to the Receiver and the Receiver connected to a camera via a 3.5mm camera audio cable. |
Operating Time | 10 hours *Measured using Insta360 Mic Pro (2 TX + 1 RX), with noise cancellation and internal recording off under interference-free conditions, with both Transmitters connected to the Receiver and Receiver connected to a camera via the 3.5mm camera audio cable. |
Onboard Memory | 32 GB |
Internal Recording Available Duration | 24-bit (Mono Internal Recording): 60 hours 24-bit (Stereo Internal Recording): 29.7 hours 32-bit (Mono Internal Recording): 44.8 hours 32-bit (Stereo Internal Recording): 22.2 hours |
RECEIVER |
|
Dimensions | 55.80×27.65×21.00 mm (L×W×H) |
Weight | 29.8g |
Wireless Mode | GFSK 1Mbps and 2Mbps |
Equivalent Isotropic Radiated Power (EIRP) | 2.400GHz-2.4835GHz: ≤ 20dBm (FCC/CE/SRRC/MIC) |
Operating Frequency | 2.400GHz-2.4835GHz |
Bluetooth Protocol | Bluetooth V5.4 |
Bluetooth Operating Frequency | 2.400GHz-2.4835GHz |
Bluetooth Transmitter Power (EIRP) | BLE: ≤ 20 dBm |
Battery Type | Li-ion |
Battery Capacity | 410mAh |
Battery Energy | 1.60Wh |
Battery Voltage | 3.89V |
Charging Specification | Max 5V |
Charging Temperature | 0℃ to 45℃ |
Operating Temperature | -10℃ to 45℃ |
Charging Time | Fully charged in approximately 75 minutes, 80% in about 27 minutes. *Tested in a lab environment with a 5V/3A charger. |
5-Minute Fast Charge | A 5-minute charge gives 1.5 hours of use. *Tested in a lab environment with the Receiver’s battery below 50%, charged with a 5V/3A charger. Noise cancellation and internal recording on Transmitter are off. Close-range recording in an interference-free environment, with the Transmitter connected to the Receiver and the Receiver connected to a camera via a 3.5mm camera audio cable. |
Operating Time | 11 hours *Measured using Insta360 Mic Pro (2 TX + 1 RX), with noise cancellation and internal recording off under interference-free conditions, with both Transmitters connected to the Receiver and Receiver connected to a camera via the 3.5mm camera audio cable. |
CHARGING CASE |
|
Dimensions | 122.00×61.90×42.20 mm (L×W×H) |
Weight | 174g (Charging Case only, without included accessories) |
Battery Type | Li-ion |
Battery Capacity | 2815mAh |
Battery Energy | 10.951Wh |
Battery Voltage | 3.89V |
Charging Specification | Max 5 V |
Charging Temperature | 0℃ to 45℃ |
Operating Temperature | -10℃ to 45℃ |
Operating Time with Charging Case | 30 hours *Measured using Insta360 Mic Pro (2 TX + 1 RX), with the Charging Case fully charged, noise cancellation and internal recording on the Transmitters are off. Close range recording in an interference free environment, with both Transmitters connected to the Receiver and the Receiver connected to a camera via a 3.5mm camera audio cable. |
Charging Time | Approx. 2 hours |
Charging Cycles for TX and RX | When charging two Transmitters and one Receiver simultaneously, a fully charged charging case can fully charge them for approx. 2 times. |
