Operating system

Windows 10 Pro 64

Processor

Intel® Core™ i7-10700 (2.9 GHz base frequency, 16 MB L3 cache, 8   cores)

Processor footnote

[6] Multi-core is designed to improve performance of certain software   products. Not all customers or software applications will necessarily benefit   from use of this technology. Performance and clock frequency will vary   depending on application workload and your hardware and software   configurations. Intel’s numbering, branding and/or naming is not a   measurement of higher performance.
  [7] Intel® Turbo Boost performance varies depending on hardware, software and   overall system configuration. See http://www.intel.com/technology/turboboost/   for more information.

Processor family

10th Generation Intel® Core™ i7 processor

Chipset

Intel® Q470

Form factor

Small form factor

MEMORY

Memory

8 GB DDR4-2933 SDRAM (2 x 4 GB)

Memory slots

4 DIMM

STORAGE

Hard drive description

256 GB Intel® PCIe® NVMe™ QLC M.2 SSD with 16 GB Intel® Optane™ memory   H10

Storage type

SSD

Optical drive

HP 9.5 mm Slim DVD-Writer

Storage Acceleration

256 GB Intel® Optane™ Memory H10 with Solid State Storage

DISPLAY AND GRAPHICS

Graphics

Intel® UHD Graphics

Graphic card footnote 2

[5] Sold separately or as an optional feature. With Blu-Ray, certain   disc, digital connection, compatibility and/or performance issues may arise,   and do not constitute defects in the product. Flawless playback on all   systems is not guaranteed. In order for some Blu-ray titles to play, they may   require a DVI or HDMI digital connection and your display may require HDCP   support. HD-DVD movies cannot be played on this PC. Don't copy   copyright-protected content.

EXPANSION FEATURES

I/O Port location

Front

Ports

1 headphone/microphone combo; 1 SuperSpeed USB Type-C® 10Gbps   signaling rate; 2 SuperSpeed USB Type-A 10Gbps signaling rate; 2 SuperSpeed   USB Type-A 5Gbps signaling rate (1 fast charging)

I/O Port location

Rear

Ports

1 audio-out; 1 power connector; 1 RJ-45; 3 SuperSpeed USB Type-A 5Gbps   signaling rate; 2 USB Type-A 480Mbps signaling rate; 2 DisplayPort™ 1.4

Expansion slots

1 M.2 2230; 1 M.2 2280; 1 PCIe 3 x16; 1 PCIe 3 x4; 1 SD 4.0 media card   reader

MEDIA DEVICES

Audio

Realtek ALC3205 codec, 2 W internal speaker, universal audio jack,   combo microphone/headphone jack

INPUT DEVICES

Pointing device

HP USB wired optical mouse

Keyboard

HP Wired Desktop 320K Keyboard

COMMUNICATIONS

Network interface type

LAN

Network interface

Intel® I210-T1 PCIe® GbE; Intel® I219LM GbE

POWER AND OPERATING REQUIREMENTS

Power

180 W external AC power adapter

Energy Efficiency Compliance

ENERGY STAR® certified

Environmental

Low halogen

DIMENSIONS AND WEIGHT

Dimensions without stand (W x D x H)

27 x 9.5 x 30.3 cm

Package dimensions (W x D x H)

39.4 x 20.5 x 49.9 cm

Weight

3.9 kg

Package weight

6.97 kg

SECURITY MANAGEMENT

Security management

Power-on password (via BIOS); SATA port disablement (via BIOS); Setup   password (via BIOS); Support for chassis padlocks and cable lock devices; USB   enable/disable (via BIOS); Serial enable/disable (via BIOS); HP Secure Erase;   HP Sure Click; HP Sure Sense; HP DriveLock and Automatic DriveLock; Trusted   Platform Module TPM 2.0 Embedded Security Chip shipped with Windows 10.   (Common Criteria EAL4+ Certified); HP Sure Recover Gen3; HP Sure Run Gen3; HP   Sure Start Gen6; HP BIOsphere Gen6; HP Client Security Manager Gen6

SOFTWARE

Management features

HP BIOS Config Utility (download); HP Client Catalog (download); HP   Driver Packs (download); HP System Software Manager (download); HP Cloud   Recovery; HP Management Integration Kit for Microsoft System Center   Configuration Management Gen 4; HP Image Assistant Gen 5

Manageability features footnote

[15] HP Driver Packs: Not preinstalled, however available for download   at http://www.hp.com/go/clientmanagement
  [16] HP Manageability Integration Kit can be downloaded from   http://www.hp.com/go/clientmanagement.
  [17] HP Cloud Recovery is available for HP Elite and Pro desktops and laptops   PCs with Intel® or AMD processors and requires an open, wired network   connection. Note: You must back up important files, data, photos, videos,   etc. before use to avoid loss of data. Detail please refer to:   https://support.hp.com/us-en/document/c05115630.
