Two-way audio input: 1-ch, RCA (2.0 Vp-p, 1kΩ) IP video input: 8-ch IP Video input: Up to 8 MP resolution Incoming bandwidth: 80Mbps Outgoing bandwidth: 80Mbps LCD/HDMI/VGA output resolution: - HDMI: 1-ch, 4K (3840 × 2160)/30Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz - VGA: 1-ch, 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz Recording Resolution: MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF Audio Output: 1-ch, RCA (Linear, 1kΩ) Synchronous Playback: 8-ch Capability: 1-ch @ 8 MP / 4-ch @ 1080p Live view / Playback: 8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF SATA: 1 SATA interface for 1 HDD Capacity: Up to 6TB capacity for each HDD Network Interface: 1RJ-45 10/100/1000Mbps self-adaptive Ethernet interface USB Interface: 2, USB2.0 Supported Standard: AF and AT Interface: 8 independent 10 /100 Mbps PoE Ethernet interfaces Max. Power: 75W Power Supply: 48 VDC Power: ≤ 90 W Consumption(without hard disk and POE): ≤ 10 W (without enabling PoE) Working Temperature: -10 oC ~ +55 oC (+14 oF~ + 131 oF) Working Humidity: 10 % ~ 90 % Chassis: 1U chassis Dimensions: 315 × 240 × 48 mm (12.4" × 9.4" × 1.9") Weight(without HDD): ≤ 1 kg (2.2 lb) |
