SPECIFICATIONS: CAMERA |
| Image Sensor | 1/2.8" Progressive Scan CMOS | Max. Resolution | 3840 × 2160 | Min. Illumination | Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR | Shutter Time | 1/3 s to 1/100,000 s | Day & Night | IR cut filter | Angle Adjustment | Pan: 0° to 355°,tilt: 0° to 75°,rotate: 0° to 355° | LENS |
| Lens Type | Fixed focal lens, 2.8 mm | Focal Length & FOV | 2.8 mm, horizontal FOV 107°, vertical FOV 57°, diagonal FOV 128° | Lens Mount | M12 | Iris Type | Fixed | Aperture | F1.6 | DORI |
| DORI | 2.8 mm: D: 88 m, O: 35 m, R: 17 m, I: 9 m | ILLUMINATOR |
| Supplement Light Type | IR | Supplement Light Range | Up to 30 m | Smart Supplement Light | Yes | IR Wavelength | 850 nm | VIDEO |
| Main Stream | 50 Hz: 20 fps (3840 × 2160) 25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) | Sub-Stream | 50 Hz: 25 fps (1280 × 720, 960×540, 640 × 480, 640 × 360) | Third Stream | 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under certain settings. | Video Bit Rate | 32 Kbps to 16 Mbps | H.264 Type | Baseline Profile,Main Profile,High Profile | H.265 Type | Main Profile | Bit Rate Control | CBR,VBR | Scalable Video Coding (SVC) | H.264 and H.265 encoding | Video Compression | Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264 (*Third stream is supported under certain settings.) | Region of Interest (ROI) | 1 fixed region(s) for main stream and sub-stream | AUDIO |
| Audio Type | Mono sound | Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC | Audio Bit Rate | 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC) | Audio Sampling Rate | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz | Environment Noise Filtering | Yes | NETWORK |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP | Simultaneous Live View | Up to 6 channels | API | Open Network Video Interface (Profile S, Profile G),ISAPI,SDK | User/Host | Up to 32 users 3 user levels: administrator, operator, and user | Security | Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface | Network Storage | NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR) | Client | iVMS-4200,Hik-Connect,Hik-Central | Web Browser | Plug-in required live view: IE 10, IE 11, Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Local service: Chrome 57.0+, Firefox 52.0+ | IMAGE |
| Image Parameters Switch | Yes | Image Settings | Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser | Day/Night Switch | Day,Night,Auto,Schedule | Wide Dynamic Range (WDR) | 120 dB | SNR | ≥ 52 dB | Image Enhancement | BLC,HLC,3D DNR | Privacy Mask | 4 programmable polygon privacy masks | INTERFACE |
| Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port | On-Board Storage | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB | Built-in Microphone | Yes | Reset Key | Yes | EVENT |
| Basic Event | Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception | Smart Event | Line crossing detection, intrusion detection (support alarm triggering by specified target types (human and vehicle)), face detection | Linkage | Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture | GENERAL |
| Power | 12 VDC ± 25%, 0.5 A, max. 6 W,Ø5.5 mm coaxial power plug,reverse polarity protection, PoE: 802.3af, Class 3, 36 V to 57 V, 0.25 A to 0.15 A, max. 7.5 W | Dimension | Ø121.4 mm × 92.2 mm (Ø4.8 × 3.6\")" | Package Dimension | 150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6") Approx. 550 g (1.2 lb.) | With Package Weight | Approx. 800 g (1.8 lb.) | Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) | Startup and Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) | Language | 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian | General Function | Heartbeat,anti-flicker,password reset via email,pixel counter | APPROVAL |
| EMC | FCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015 | Environment | CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006 | Protection | IP67: IEC 60529-2013;IK10: IEC 62262:2002 | Safety | UL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005 |
|
