PORTS |
|
Gigabit Ethernet Ports | 48 |
SFP/SFP+ Ports | 6 × SFP+ |
Maximum Number of Supported Modules | SM-10G: 6 MM-10G: 6 RJ45-10G: 3 *Note: RJ45-10G modules must be interval inserted |
MGMT Ports | 1 × Console port |
Others | 1 × Reset Pinhole |
LEDS |
|
System LEDs | 1× tri-color LED for device tracking and status indication |
Power Supply LEDs | 2 × green LEDs, one for each power source (PWR & RPS) |
Data Transferring LEDs | 54 × green-color LEDs |
PoE Supply LEDs | 48 × yellow-color LEDs |
SYSTEM |
|
Flash | 8 MB Nor Flash, 128 MB Nand Flash |
RAM | 512 MB RAM |
CPU | Dual-core, MIPS interAptiveTM 1GHz |
Forwarding Mode | Store-and-forward |
Total non-blocking throughput | 108 Gbps |
Switching Capability | 216 Gbps |
Forwarding Rate | 160.704 Mpps |
Packet Buffer | 8.4 Mb |
Network Latency | <4 µs |
POWER SUPPLY |
|
Power Supply | 100–240 V AC, 50/60 Hz |
Power Redundancy Scheme | 1+1 External RPS |
External Redundant Power Supply (Pending) | 460 W |
Max Power Consumption | 65.4 W 509.3 W (PoE 400 W) |
Max Output Power | 509.3 W |
POE |
|
PoE Standards | IEEE 802.3af/at |
PoE Ports | 48 |
Max Output Power per PoE Port | 30 W |
Max Total PoE Output Power | 400 W |
PHYSICAL |
|
Unit Dimension | 440 mm × 300 mm × 44 mm (17.32″ × 11.81″ × 1.73″) (L × W × H) |
Unit Weight | 5.05 kg (11.13 lb) |
Mounting | Desktop, or Rack-Mount (rack-mounting kits included) |
Package Content | 1 × Switch 1 × 25 cm (9.84″) Ground Cable 4 × Rubber Footpads 1 × Power Cord Anti-Trip 8 × Flat Head Machine Screws (M3 × 6 mm) 1 × 1.2 m (3.94 ft) AC Cable of 10 A 1 × Simplified Quick Installation Guide 1 × Regulatory Paper 2 × Rack-Mounting Kits |
ENVIRONMENTAL |
|
Temperature | Operating: 0 °C to 45 °C (32 °F to 113 °F ) Storage: -10 °C to 60 °C (14 °F to 140 °F ) |
Humidity | Operating: 10%–90% (RH), non-condensing Storage: 5%–95% (RH), non-condensing |
MTBF | 70,000 hours |
Fan | 4 |
CPU Monitoring | Monitoring CPU usage, over-CPU usage alarming |
Memory Usage | Monitoring memory usage, over-memory usage alarming |
Power Supply Monitoring | Monitoring of power supply model and status Power supply failure alarming |
Fan Monitoring | Automatic speed adjustment Fan failure alarming |
Temperature Monitoring | Temperature monitoring, over-temperature alarming |
Surge Protection | ±6 kV CM for power ±4 kV CM for network ports |
ESD | ±12 kV for contact discharge |
COMPLIANCE |
|
Certification | FCC, CE, RCM, IC |
