Memory

128 MB RAM, 32 MB Flash

Jumbo Frame (Bytes)

10240

PoE Standards

/

Gigabit Ethernet Ports

16

1G SFP Ports

4

Console

1

PoE Ports

/

Integrated Power Supply

30 W

Max Output Power per PoE Port

/

Max Total PoE Output Power

/

PoE Standards

/

Surge Protection

± 6 kV CM and DM for power

± 4 kV CM for network ports

ESD

± 12 kV for contact discharge

Other Ports

1 × Reset Pinhole

Forwarding Mode

Store-and-forward

Total non-blocking throughput

20 Gbps

Switching Capability

40 Gbps

Forwarding Rate

29.76 Mpps

Packet Buffer

4.1 Mb

Network Latency Avg

<4 μs

Switching

• 8K MAC addresses, including static, dynamic, filtering and sticky MAC address

• 4K VLANs, port-based VLAN, IEEE 802.1Q VLAN tagging, MAC-based VLAN, protocol-based VLAN,QinQ

• Voice VLAN including auto voice VLAN, tagged OUI and untagged OUI

• 16 VLAN virtual interface with 9216 MTU

• 256 ARP/NDP

• 8 link aggregation groups

• Spanning tree, 16 instances for STP/RTSP/MSTP/PVST(+)/RPVST(+)

Routing

32(IPv4)/32(IPv6) static routing, which supports user-defined static routing entries

Multicast

• IGMP Snooping with IGMPv2 and IGMPv3, 256 IGMP Snooping groups

• MLD Snooping with MLDv1 and MLDv2, 256 MLD Snooping groups

• MVR

QoS/ACL

• Port priority

• Priority mapping

• Queue scheduling, including SP, WRR, WFQ, SP-WRR and SP-WFQ

• Traffic shaping

• Rate limit

• 128 ACLs for Ethernet, IPv4, and IPv6 with 1.5K total ACEs

DHCP

DHCP server, DHCP relay, Option 82, 60,160 and 43

Maintenance

• CPU and memory monitoring

• Fault detection and alarm for fan

• SNMP including SNMPv1, SNMPv2c, SNMPv3

• RMON

• LLDP&LLDP-MED

• Backup and restore

• Syslog

• Alert

• Diagnostics include Ping, Ping Watchdog, Traceroute, Port Mirroring (SPAN and   RSPAN), UDLD (TBD), copper testing, fiber module monitoring, and one-click

debugging

• Upgrade via FTPS / TFTP / HTTP / HTTPS or local upload, mass provisioning using DHCP Option / TR-069 (pending) / GDMS Networking / GWN Manager / GWN

router

Security

• User hierarchical management and password protection, HTTPS, SSH, Telnet

• Identity authentication including 802.1X and MAC authentication

• AAA authentication including RADIUS, TACACS+

• Storm control

• Port isolation, port security, sticky MAC

• Filtering MAC address

• IP/IPv6 source guard, DoS attack prevention, ARP inspection

• DHCP/DHCPv6 Snooping

• Loop protection including BPDU protection, root protection and loopback protection

• Kensington Security Slot (Kensington Lock) support

• Firmware signature

LEDs

1 x tri-color LED for

device   tracking and status

indication

20 x green LEDs for data

ports

Fan

/

Environmental

Operating Temperature: 0 °C to 45 °C (32 °F to 113 °F ); Operating Humidity: 10–90%   (RH), non-condensing

Storage Temperature: -10 °C to 60 °C (14 °F to 140 °F ), Storage Humidity: 5%–95%, non-condensing

Dimensions

440 mm × 200 mm × 44 mm (17.32″ × 7.87″ × 1.73″) (L × W × H)

Unit Weight

2.6 kg (5.73 lb)

Mounting

Desktop, Wall Mount, or Rack Mount (rack mounting kits included)

Package Content

1 × Switch

1 × 1.2 m (3.94 ft) AC Cable of 10 A

1 × 25 cm (9.84″) Ground Cable

1 × Simplified Quick Installation Guide

1 × Regulatory Information

4 × Rubber Footpads

8 × Flat Head Machine Screws (M3 × 6 mm)

2 x Rack Mounting Kits

Compliance

FCC, CE, RCM, IC, UKCA
