Gigabit Ethernet Ports

4x Combo

1G SFP Ports

24

10G SFP+ Ports

4

Note: Support DAC Cable and must be ≤ 5m

Maximum no. of Supported Modules

SM-1G: 24

MM-1G: 24

RJ45-1G: 12

SM-10G: 4

MM-10G: 4

RJ45-10G: 2

Console

1

Integrated Power Supply

60W

External Redundant Power Supply (RPS)

12V/60W

Surge Protection

± 6KV CM and DM for power

± 4KV CM for network ports

ESD

± 12KV for contact discharge

Auxiliary Ports

1x Reset Pinhole

Forwarding Mode

Store-and-forward

Total non-blocking throughput

64Gbps

Switching Capability

128Gbps

Forwarding Rate

95.232Mpps

Packet Buffer

12Mb

Network Latency

<4µs

Switching

• 16K MAC addresses, including static, dynamic and filtering MAC address

• 16 VLAN virtual interface with 9216 MTU

• 1K ARP/NDP

• 4K VLANs, port-based VLAN, IEEE 802.1Q VLAN tagging, Mac-based VLAN, protocol-based VLAN

• Private VLAN

• VOICE VLAN including auto voice VLAN, tagged OUI, and untagged OUI

• GVRP(pending)

• 32 link aggregation groups

• ERPS(pending)

Spanning tree, 32 instances for STP/RSTP/MSTP/PVST(+)/RPVST(+)

Routing

• 512 (IPv4)/128(IPv6) routes

• 32(IPv4)/32(IPv6) static routing

• Policy routing (pending)

• Dynamic routing, including RIP, RIPng, OSPF, OSPFv3, and BGP

• Routing Policy

• VRRP(pending)

Multicast

• IGMP Snooping with IGMPv2 and IGMPv3, 256 IGMP Snooping groups

• MLD Snooping with MLDv1 and MLDv2, 256 MLD Snooping groups

• MVR

QoS/ACL

• Port priority

• Priority mapping

• Queue scheduling, including SP, WRR, WFQ, SP-WRR and SP-WFQ

• Traffic shaping

• Rate limit

2K ACL for Ethernet, IPv4 and IPv6

DHCP

DHCP server, DHCP relay, Option 82, 60, 160 and 43

Maintenance

• CPU and memory monitoring

• Fault detection and alarm for power supply and fan

• SNMP including SNMPv1, SNMPv2c, SNMPv3

• RMON

• LLDP&LLDP-MED

• Backup and restore

•Syslog

• Diagnostics including Ping, Traceroute, Mirroring including SPAN and RSPAN,   UDLD(TBD)and copper test

• Upgrade via FTPS / TFTP / HTTP / HTTPS or local upload, mass provisioning using DHCP Option/ TR-069(pending) / GDMS Networking / GWN Manager / GWN router

Security

• User hierarchical management and password protection, HTTPS, SSH, Telnet

• Identity authentication including 802.1X and MAC authentication

• AAA authentication including RADIUS, TACACS+

• Storm control

• Port isolation, port security, sticky MAC

• Filtering MAC address

• IP/IPv6 source guard, DoS attack prevention, ARP inspection

• DHCP/DHCPv6 Snooping

• Loop protection including BPDU protection, root protection and loopback protection

• Kensington Security Slot (Kensington Lock) support

Mounting

Desktop, Wall-Mount or Rack-Mount(rack-mounting kits included)

System LEDs

1x tri-color LED for device tracking and status indication

Power Supply LEDs

/

Data Transferring LEDs

32 green-color LEDs

Fan

/

Environmental

Operation: 0°C to 45°C, humidity 10% to 90% RH(Non-condensing)

Storage: -10°C to 60°C, humidity: 10% to 90% RH(Non-condensing)

Dimensions

440mm(L)x200mm(W)x44mm(H)

Unit Weight

3.15Kg

Package Contents

1x Switch

1x 1.2m(10A) AC Cable

1x 25cm Ground Cable

4x Rubber Footpads

1x Power Cord Anti-Trip

2x Rack-Mounting Kits

8x Screws(KM 3*6)

1x Simplified Quick Installation Guide

1x Regulatory Paper

1x RPS

Compliance

FCC, CE, RCM, IC, UKCA
