Core Clock

Boost Clock* : up to 2920 MHz

Game Clock* : up to 2340 MHz

Stream Processors

3072

Memory Clock

18   Gbps

Memory Size

12GB

Memory Type

GDDR6

Memory Bus

192 bit

Card Bus

PCI-E 5.0

Digital max resolution

7680 x 4320

Multi-view

4

Card size

L=288 W=132 H=50 mm

PCB Form

ATX

DirectX

DirectX 12 API

OpenGL

OpenGL 4.6

Recommended PSU

750W

Power Connectors

8   pin*2

Output

DisplayPort 2.1a x2

HDMI 2.1b x2

Accessories

Quick guide

Note

* “Boost Clock” is the maximum frequency achievable on the GPU running a bursty   workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads. GD-151

* “Game Clock” is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary. GD-147
