DSL / Internet

Integrated modem for all (V)DSL connections up to 300 Mbit/s (including supervectoring) and ADSL2+

Router operation via WAN even with cable or fibre optic modem (ONT)

Fallback protection via USB dongle

MyFRITZ! – secure access to your own FRITZ!Box from anywhere

VPN (WireGuard / IPSec)

Firewall / NAT with port sharing

Wake on LAN

Parental controls (time budget, youth protection filter, device block)

Wi-Fi

Up to 7.1 Gbit/s via Wi-Fi 7

5 GHz: up to 5760 Mbit/s

2.4 GHz up to 1376 Mbit/s

4 x 4 MIMO

Mesh Wi-Fi

Compatible with the IEEE   802.11a/g/n/ac/ax/be Wi-Fi standards

Wi-Fi network encryption with WPA3/WPA2

Easy connection at the touch of a button (WPS)

Wi-Fi guest access / hotspot with captive portal

Wi-Fi eco mode for optimum performance at minimum power consumption

Switch Wi-Fi on and off using button, FRITZ!Fon, FRITZ!App, or by schedule

Smart Home / Media

Smart home features for energy, heating, lighting, and more

Supports smart home devices in accordance with the DECT ULE standard

Supports Zigbee for smart home devices from other manufacturers (Zigbee compatibility list)

Automation in the smart home with schedules, scenes, and routines with if-then combinations

Operation of your FRITZ! Smart Home via the FRITZ!Box user interface, FRITZ!Fon, FRITZ!DECT-Taster and FRITZ!App Smart Home

FRITZ!NAS: Central storage for all data in the home network

Media server for music, photos, and videos in the home network (DLNA/UPnP AV)

Ideal for IPTV and streaming music and videos

Telefony

Phone system with DECT base station for up to six cordless phones

With FRITZ!Fon additional functions (e.g. calendar or weather forecast)

Sockets for two analogue phones, answering machine or fax

Registration of IP phones (LAN/Wi-Fi) SIP-compliant

Voice transmission encrypted upon delivery

Supports HD telephony for natural sound

DECT Eco: Wireless network switches off when DECT phones on standby

5 integrated answering machines with option for emailing voice messages

Local and online phone books (Google, Apple, CardDAV and more)

Fax function with option for emailing fax message

Call diversion, internal calls (intercom), three-way conferencing, call transfer, phone number blocks and Do Not Disturb

FRITZ!OS

Intuitive browser- and app-based user interface

Free FRITZ!Apps for smartphone: MyFRITZ!App, FRITZ!App Smart Home, FRITZ!App Fon, FRITZ!App Wi-Fi, FRITZ!App TV

Context-sensitive Online Help

Push service mails for events in the home network

Security functions with diagnostic tool, auto-updates, firewall, and filter functions

Optional energy-saving mode for even more energy efficiency

Free updates with new functions and optimizations

Device Properties

Dimensions (W x H x D): 254 x 63 x 191 mm

Can be wall mounted

Average power consumption: 12 - 13 W

Information on data usage in accordance with Regulation (EU) 2023/2854 (Data Act)
