Scanning Speed

40 ppm

Document Size - Multiple Sheets - Width

50.8 mm to 215.9 mm

Document Size - Multiple Sheets - Length

50.8 mm to 355.6 mm

Document Size - Single Sheet - Width

50.8 mm to 215.9 mm

Colour / Monochrome

Yes / Yes

2-Sided (Duplex) Scan

Yes

Colour Depth - Input

48-bit colour processing

Colour Depth - Output

24-bit colour processing

Resolution - Optical

Up to 600 dpi × 600 dpi

Resolution - Interpolated

Up to 1,200 dpi × 1,200 dpi

Document Scanning Width / Length

Up to 215.9 mm

Product Dimensions (Width X Depth X Height)

300 mm × 216 mm × 191 mm

Weight

2.7 kg

ADF (Automatic Document Feeder)

Up to 60 sheets (Paper: 20 lb (80 g/m²) A4/Letter size)

Memory Capacity

512 MB

What's in The Box

Scanner, Quick Setup Guide, User's Guide, Network Guide, CD-ROM's, ADF Document Output Support, AC Adaptor, USB Cable

CONNECTIVITY

Connectivity

Ethernet 10Base-T/100Base-TX, Wireless LAN IEEE 802.11 b/g/n (Infrastructure Mode), IEEE 802.11 g/n (Wi-Fi Direct), Super Speed USB 3.0, IEEE 802.11 g (Wi-Fi Direct)

NETWORK

Wireless Network Security

WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (AES), WPA3

Setup Support Utility

WPS

WLAN Assistant

DISPLAY TYPE

Touchscreen LCD

2.8 in. (71.1mm) TFT colour LCD screen

OPERATION

Power Source

AC: 100-240 V, 50/60 Hz

Power Consumption - Scanning

Approx. 25W

Power Consumption - Ready

Approx. 7.3W

Power Consumption - Power Saving / Deep Sleep

Approx. 1.7W

Power Consumption - Power OFF

Approx. 0.1W

Temperature Operating

5°C to 35°C

Humidity - Operating

20% to 80%

Humidity - Storage

10% to 90%

COMPLIANCE

TWAIN Compliant - Windows®

Windows Server 2016 / Windows Server 2019 / Windows Server 2022

TWAIN Compliant - Macintosh

macOS v10.14.x / 10.15.x / 11.0.x / 11.1.x

WIA Compliant - Windows®

Windows 10 / Windows 11

ICA Compliant - Macintosh

macOS v10.14.x / 10.15.x / 11.0.x / 11.1.x

ISIS™ Compliant - Windows®

Windows 10 / Windows 11
