Aten USB Console Extender w/USB type A&B dataport 1600x1200 @ 250m

The CE800B USB KVM Extender transmits VGA/HD video up to 1600×1200@60 Hz over Cat‑5e up to 250 m, supports dual consoles with push‑button switching, on‑board audio, USB mass‑storage, surge/ESD protection, gain control and upgradable firmware.

Aten USB Console Extender w/USB type A&B dataport 1600x1200 @ 250m
  • 20511
$355.50
or 4x fortnightly payments of $330 with ZipPay
Learn more

Pick Up Time :

Delivery:

- +
Want a stock alert?

Please enter a valid email address

By clicking 'Notify Me', you agree to our Terms & Conditions and consent to receive email updates. You can unsubscribe at any time.

WishAdd to Wishlist

   Your Store   Question Mark

Your store is set to:

Check live stock level
    • DELIVERY
    • Post Out Of Stock
    QLD Pickup
    • Chermside New Out Of Stock
    • Southport Out Of Stock
    • Hillcrest Icon 3 Out Of Stock
    • Brendale Out Of Stock
    NSW Pickup & Post
    • Post Out Of Stock
    • Villawood Robot Super StoreIcon 3 Out Of Stock
    • West Ryde Out Of Stock
    • Ultimo Out Of Stock
    • Auburn Out Of Stock
    • Annandale Out Of Stock
    • Crows Nest New Out Of Stock
    • Carlingford New Out Of Stock
    • Hurstville New Out Of Stock
    • Mosman New Out Of Stock
    • Parramatta New Out Of Stock
    • Goulburn New Out Of Stock
    VIC Pickup & Post
    • Post Out Of Stock
    • Mulgrave Robot Super StoreIcon 3 Out Of Stock
    • Mitcham Out Of Stock
    • Essendon Out Of Stock
    • Dandenong South Icon 3 Out Of Stock
    ACT Pickup
    • Fyshwick Out Of Stock
    SA Pickup & Post
    • Post Out Of Stock
    • Croydon Robot Super StoreIcon 3 Out Of Stock
    • Holden Hill Out Of Stock
    • Adelaide CBD Icon 3 Out Of Stock
    WA Pickup & Post
    • Post Out Of Stock
    • Belmont Robot Super StoreIcon 3 Out Of Stock
    • Balcatta Out Of Stock
    TAS Post
    • Post Out Of Stock
    • Glenorchy

Bell  Stock Levels May Vary

Stock is different at each store. To secure your item, order online.
Walk-ins are still welcome but stock isn’t guaranteed.

Our team is ready to help! Please contact us if you have any questions about product specifications, stock availability, or compatibility.




CE800B
     USB KVM Extender


     The CE800B USB KVM Extender with on-board audio allows access to a computer system from a remote console (USB keyboard and mouse, monitor, stereo speakers, and microphone). It is perfect for factory and construction sites, or any type of installation where the console needs to be in a conveniently accessible location, but you want the system equipment to reside in a safe place - away from dust, dirt, and harsh environmental influences.

     The CE800B has built-in USB ports that support USB Mass Storage compliant flash drives. The addition of a Type B USB port on the local unit means that the flash drive facility is fully supported in both PC-only and KVM switch installation.




Package Contents

  • 1x CE800BL USB KVM Extender (Local Unit)

  • 1x CE800BR USB KVM Extender (Remote Unit)

  • 1x Custom KVM Cable (1.8 m)

  • 2x Power Adapters

  • 1x Firmware Upgrade Cable

  • 1x USB Cable (1.8 m)

  • 1x Mounting Kit

  • 1x User Instructions

  • 1x Grounding Information Card

Features

  • Cat 5e cable to connect the Local and Remote Units - up to 250 m (825 ft) apart

  • Dual console operation - control your system(s) from both the local and remote consoles

  • Pushbutton selection of the active console

  • Built-in USB port on both units supports external USB Mass Storage compliant flash drives for easy file sharing

  • Special security feature requires login when mounting an external USB storage device on the remote unit

  • Supports Wide Screen formats *

  • Supports VGA, SVGA, and multisync monitors ?local monitor supports DDC; DDC2; DDC2B

  • High resolution video - up to 1600 x 1200 @ 60 Hz

  • Built-in 8KV/15KV ESD protection and 2KV surge protection

  • Adjustable gain control - automatically and manually adjusts signal strength to compensate for distance

  • Supports stereo speakers and stereo microphone

  • Supports Microsoft Intellimouse and the scrolling wheel on most mice

  • Upgradable firmware

  • Built-in ASIC for greater reliability and compatibility

         * The EDID data for a widescreen is sent from the local video output port. For widescreen modes and displays connect the monitor to the local video output port or use an ATEN EDID emulator.

Computer Connections

CE800BL x1

Console

Keyboard 1 x USB Type A Female (White)
   Video 1 x HDB-15 Female (Blue)
   Mouse 1 x USB Type A Female (White)
   Speakers 1 x Mini Stereo Jack (Green)
   Microphone 1 x Mini Stereo Jack (Pink)

KVM Ports

CE800BL

Keyboard/ Video / Mouse 1 x SPHD-15 Female (Yellow)
     USB Port
     1 x USB Type B (Female)
     1 x USB Type A (Female)
     1 x USB Type A (Female)
     Speakers 1 x Mini Stereo Jack (Green)
     Microphone 1 x Mini Stereo Jack (Pink)

CE800ER

USB Port
     1 x USB Type A (Female

F/W Upgrade CE800BL

1 x 4-conductor 3.5 mm Jack

Power1 x DC Jack
Unit to Unit (Link)1 x RJ-45
SwitchesOperating Mode Selection 1 x Pushbutton
   Compensation CE800ER 2 x Pushbutton
LEDs

Local CE800BL 1 (Green)
   Remote CE800BL 1 (Green) 1 (Green)
   Link N/A CE800ER 1 (Green)
   Compensation CE800ER 1 (Orange)

Video1920x1200@60Hz at 30m; 1600x1200@60Hz at 150m; 1024x768@60Hz at 250m
Power ConsumptionDC5V, 6W
EnvironmentOperating Temp. 0-50C
   Storage Temp. -20-60C
   Humidity 0-80% RH, Non-condensing
Physical PropertiesHousing Metal
   Weight 0.50 kg
   Dimensions (L x W x H) 20.00x8.15x2.63cm


* Specifications are subject to change without notice.
* Specifications may vary.
* The product picture(s) is only for your reference, it may differ from the actual product.

Aten USB Console Extender w/USB type A&B dataport 1600x1200 @ 250m

  • Product Name:
    Aten USB Console Extender w/USB type A&B dataport 1600x1200 @ 250m
  • Model Number:
    CE800B-AT-U
  • Brand:
    Aten Aten
  • Warranty Period:
    1 Year
