COMPUTER

1 x USB-C Male

DEVICE

1 x USB 3.1 Gen1 Type A Female   with BC1.2*
  2 x USB 3.1 Gen1 Type A Female*

  *The total output of 3 x USB 3.1 Gen1 Type A Female is 10W (5V/2A).

VIDEO OUTPUT

1 x DisplayPort Female
  1 x HDMI Female
  1 x VGA Female

LAN PORTS

1 x Gigabit Ethernet Female

AUDIO

1 x 3.5mm stereo 4-pole   microphone and headphone jack

POWER

Supports USB Power Delivery 2.0   for laptop charging up to 60W, power profiles include 5V, 9V, 12V, 20V   (additional USB-C power adapter needed)*

  *Supports USB-C PD power adapter only, cannot work with USB-C QC power   adapter.

FLASH MEMORY

1 x SD/SDHC/SDXC card slot*
  1 x Micro SD/SDHC/SDXC (up to 128 GB) card slot*

  *SD and Micro SD Card cannot be used at the same time; functionality accords   to the order of insertion.

VIDEO RESOLUTION

Single-View :*
  DisplayPort - 3840 x 2160@30
  HDMI - 3840 x 2160@30
  VGA - 1920 x 1200@60

  Dual-View :**
  DisplayPort/HDMI - 1920 x 1080@60
  DisplayPort/VGA - 1920 x 1080@60

  *With Intel 7th-Generation Core Processor (Kaby Lake) and above. More info   about CPU generation, please find:   https://www.intel.com/content/www/us/en/processors/processor-numbers.html
  For video output to work through a USB-C port, device with DP Alt Mode   support is required.
  ** For Dual-View to work, a computer's graphics card must support MST   technology. Mac computers only support a single-view output.


POWER CONSUMPTION

5V:15WBTU

OPERATING TEMPERATURE

0°C to 40°C (32°F to 122°F)

STORAGE TEMPERATURE

-10°C to 70°C (-4°F to 158°F)

HUMIDITY

10% to 90% relative humidity,   non-condensing

HOUSING

Aluminum

WEIGHT

0.32 kg ( 0.7 lb )

DIMENSIONS (L X W X H)

28.00 x 7.50 x 1.45 cm
  (11.02 x 2.95 x 0.57 in.)

NOTE

For some of rack mount   products, please note that the standard physical dimensions of WxDxH are   expressed using a LxWxH format.
