Aten 8 Port PS/2-USB 2.0 KVMP Online Switch (CS1708I)

Aten 8 Port PS/2-USB 2.0 KVMP Online Switch (CS1708I)
  • 50141_thumb_P_1552522072575
  • 50141_thumb_P_1552522087929
  • 50141_thumb_P_1552522087808
$998.5
or 4x fortnightly payments of $330 with ZipPay
Learn more

Pick Up Time :

Delivery:

- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

WishAdd to Wishlist

Buy Now, Pay Later:
Buy now with PayPal
   Your Store   Question Mark

Your store is set to:

Check live stock level

Bell  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Pickup.

Specifications

  • Product Name:
    Aten 8 Port PS/2-USB 2.0 KVMP Online Switch (CS1708I)
  • Model Number:
    CS1708I-AT-U
  • Brand:
  • Manufacturer Warranty:
    2 Year

Description

Aten 8 Port PS/2-USB 2.0 KVMP Online Switch (CS1708I)


  • Superior video quality - up to 2048 x 1536; DDC2B for the local console; up to 1920 x 1200 @ 60Hz** and 1600 x 1200 @ 60Hz / 24 bit color depth for remote sessions

  • Supports TLS 1.2 data encryption and RSA 2048 bit certificates for secure user logins from a browser

  • Panel array mode enables user to monitor multiple servers from single screen at the same time - each selected server's video output appears in a separate panel - users can easily select the number of panels to view




Specifications


Computer Connections
Direct8
Maximum128 (via daisy chain)
Port SelectionOSD/GUI; Hotkey; Pushbutton
Connectors
Console Ports1 x SPHD-18 Male (Yellow)
KVM Ports8 x SPHD-17 Female (Yellow)
Daisy Chain Ports1 x DB-25 Male
Power1 x DC Jack
LAN Ports1 x RJ-45 Female
Firmware Upgrade1 x RJ-11
USB Port1 x USB Type A Female
Switches
Reset1 x Semi-recessed Pushbutton
Port Selection8 x Pushbutton
Firmware Upgrade Recovery1 x Slide
LEDs
Online8 (Orange)
Selected8 (Green)
Station ID1 x 2-digit, 7-segment (Orange)
Power1 (Dark Green)
10/100 Mbps1 (Orange/Green - at LAN port)
Emulation
Keyboard / MousePS/2, USB
Video
Local2048 x 1536; DDC2B
RemoteFHD : 1920 x 1200 @ 60Hz
Non-FHD : 1600 x 1200 @ 60Hz
Scan Interval1–255 sec.
Power ConsumptionDC5.3V:7.67W:55BTU
Environmental
Operating Temperature0–50°C
Storage Temperature-20–60°C
Humidity0–80% RH, Non-condensing
Physical Properties
HousingMetal
Weight2.81 kg ( 6.19 lb )
Dimensions (L x W x H)43.72 x 15.96 x 4.40 cm
(17.21 x 6.28 x 1.73 in.)
NoteFor some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.


Package Contents

  • 1x CS1708i KVM over IP Switch

  • 1x Custom KVM Cable (VGA, USB; 1.8m/6ft)

  • 1x Custom KVM Cable (VGA, PS/2; 1.8m/6ft)

  • 1x Custom Console Cable (VGA, USB, PS/2; 27cm/0.88ft)

  • 1x Firmware Upgrade Cable

  • 1x Mounting Kit

  • 1x Foot Pad Set (4 pcs)

  • 1x Power Adapter

  • 1x User Instructions
