Aten 4 Port USB 3.0 4K Dual DisplayPort KVMP Switch (CS1944DP)

Aten 4 Port USB 3.0 4K Dual DisplayPort KVMP Switch (CS1944DP)
  • 50140_thumb_P_1552524844651
  • 50140_thumb_P_1552524876583
  • 50140_thumb_P_1552524876377
  • 50140_thumb_P_1552525069085
$1,007.5
or 4x fortnightly payments of $330 with ZipPay
Learn more

Pick Up Time :

Delivery:

- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

WishAdd to Wishlist

Buy Now, Pay Later:
Buy now with PayPal
   Your Store   Question Mark

Your store is set to:

Check live stock level

Bell  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Pickup.

Specifications

  • Product Name:
    Aten 4 Port USB 3.0 4K Dual DisplayPort KVMP Switch (CS1944DP)
  • Model Number:
    CS1944DP-AT-U
  • Brand:
  • Manufacturer Warranty:
    2 Year

Description

Aten 4 Port USB 3.0 4K Dual DisplayPort KVMP Switch (CS1944DP)


  • Superior video quality – 4096 x 2160 @ 60Hz and 3840 x 2160 @ 60Hz; 2-Port USB 3.1 Gen 1 hub with SuperSpeed 5 Gbps data transfer rates

  • Quad-Display – Easily connect two CS1944DP units for a second dual-screen setup controlled through a single connection

  • Multi-Stream Transport (MST) allows multiple monitors through a single DisplayPort connector

  • DisplayPort Dual – Mode technology (DP++) supports HDMI and DVI signals via a DisplayPort-to-HDMI/DVI DP++ adapter



Specifications


Computer Connections4
Port SelectionHotkey, Pushbutton, Mouse, RS-232 Commands
Video4096 x 2160 @ 60Hz
Connectors
Console Ports2 x USB Type A Female
2 x DisplayPort Female (Black)
2 x 3.5mm Audio Jack Female (Green; 1 x front, 1 x rear)
2 x 3.5mm Audio Jack Female (Pink; 1 x front, 1 x rear)
KVM (Computer) Ports4 x USB3.1 Gen1 Type B Female (Blue)
8 x DisplayPort Female (Black)
4 x 3.5mm Audio Jack Female (Green)
4 x 3.5mm Audio Jack Female (Pink)
Daisy Chain Ports1 x RJ-45 Female
Power1 x DC Jack
USB Hub2 x USB3.1 Gen1 Type A Female (Blue; 1 x front; 1 x rear)
Switches
Selected5 x Pushbutton
Station Selection1 x Slide Switch
Emulation
Keyboard / MouseUSB
Scan Interval1-99 seconds (default: 5 seconds)
Power ConsumptionDC12V:5.76W:84BTU
Environmental
Operating Temperature0–50°C
Storage Temperature-20–60°C
Humidity0-80% RH, Non-condensing
Physical Properties
HousingMetal
Weight1.51 kg ( 3.33 lb )
Dimensions (L x W x H)33.50 x 15.66 x 4.40 cm
(13.19 x 6.17 x 1.73 in.)
NoteFor some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.

Package Contents

  • 1x 4-Port USB 3.0 4K DisplayPort Dual Display KVMPâ„¢ Switch

  • 8x DisplayPort 1.2 Cables

  • 4x USB 3.0 Cables

  • 8x Audio Cables

  • 1x Power Adapter

  • 1x User Instructions
