Aten 4 Port USB 2.0 HDMI KVMP Switch (CS1794C-AT-U)

Aten 4 Port USB 2.0 HDMI KVMP Switch (CS1794C-AT-U)
  • 50128_thumb_P_1552525685461
  • 50128_thumb_P_1552525697766
  • 50128_thumb_P_1552525697532
$368.5
or 4x fortnightly payments of $330 with ZipPay
Learn more

Pick Up Time :

Get a $5 credit or a free drink if order not ready on pick up time.

Delivery:

- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

WishAdd to Wishlist

Buy Now, Pay Later:
Buy now with PayPal
   Your Store   Question Mark

Your store is set to:

Check live stock level

Bell  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Pickup.

Specifications

  • Product Name:
    Aten 4 Port USB 2.0 HDMI KVMP Switch (CS1794C-AT-U)
  • Model Number:
    CS1794-AT-U
  • Brand:
  • Manufacturer Warranty:
    2 Year

Description

Aten 4 Port USB 2.0 HDMI KVMP Switch (CS1794C-AT-U)


  • Superior video quality - supports 480i, 480p, 720p, 1080i, and 1080p(HDTV)/1920 x 1200(DVI)

  • PC selection via pushbutton and hotkeys

  • Video DynaSync™ - stores the console monitor's EDID (Extended Display Identification Data) to optimize display resolution

  • Multiplatform support - Windows, Linux,and Mac




Specifications


Computer Connections4
Port SelectionHotkey, Pushbutton
Connectors
Console Ports2 x USB Type A Female (rear panel)
1 x HDMI Female (Black)
2 x 3.5 mm Audio Jack Female (Green; 1 x front, 1 x rear)
2 x 3.5 mm Audio Jack Female (Pink; 1 x front, 1 x rear)
KVM Ports4 x USB Type B Female
4 x HDMI Female (Black)
4 x 3.5 mm Audio Jack Female (Green)
4 x 3.5 mm Audio Jack Female (Pink)
Firmware Upgrade1 x 3.5 mm Audio Jack Female (Black)
Power1 x DC Jack
USB Hub2 x USB Type A Female (1 x front panel; 1 x rear panel)
Switches
Selected5 x Pushbutton
LEDs
Audio5 (Green)
KVM5 (Orange)
USB5 (Green)
Emulation
Keyboard / MouseUSB
Video1920 x 1080 @ 60Hz / 1920 x 1200 @ 60Hz
Scan Interval1-99 seconds (default: 5 sec.)
Power ConsumptionDC5.3V:3.62W:43BTU
Environmental
Operating Temperature0-50°C
Storage Temperature-20-60°C
Humidity0-80% RH, Non-condensing
Physical Properties
HousingMetal, Plastic
Weight0.53 kg ( 1.17 lb )
Dimensions (L x W x H)26.23 x 7.68 x 4.40 cm
(10.33 x 3.02 x 1.73 in.)
NoteFor some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.


Package Contents

  • 1x CS1794 USB 2.0 HDMI KVMP™ Switch

  • 4x KVM Cable (HDMI, USB, Audio; 1.8m/6ft)

  • 1x Firmware Upgrade Cable

  • 1x Power Adapter

  • 1x User Instructions
