Aten 16 Port Rackmount USB 2.0 HDMI KVMP Switch (CS-17916)

Aten 16 Port Rackmount USB 2.0 HDMI KVMP Switch (CS-17916)
  • 50145_thumb_P_1552521319751
  • 50145_thumb_P_1552521330679
  • 50145_thumb_P_1552521330488
$1,762.5
or 4x fortnightly payments of $330 with ZipPay
Learn more

Pick Up Time :

Delivery:

- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

WishAdd to Wishlist

Buy Now, Pay Later:
Buy now with PayPal
   Your Store   Question Mark

Your store is set to:

Check live stock level

Bell  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Pickup.

Specifications

  • Product Name:
    Aten 16 Port Rackmount USB 2.0 HDMI KVMP Switch (CS-17916)
  • Model Number:
    CS17916-AT-U
  • Brand:
  • Manufacturer Warranty:
    2 Year

Description

Aten 16 Port Rackmount USB 2.0 HDMI KVMP Switch (CS-17916)


  • Cascadable to two levels–control up to 256 computers

  • Multi-Display feature – stack up to eight CS17916 units and display video from up to eight monitors(dual display/triple display/quad display/multi-display)

  • Video DynaSyncâ„¢ – exclusive ATEN technology eliminates boot-up display problems and optimizes resolution when switching between ports

  • Broadcast mode - operations simultaneously performed on all selected computers, software installation and upgrading, system wide shutdown, etc.




Specifications


Computer Connections
Direct16
Maximum256 (via Cascade)
Port SelectionOSD, Hotkey, Pushbutton
Connectors
Console Ports1 x HDMI Female
2 x USB Type A Female
2 x 3.5mm Audio Jack Female (Green; 1 x front panel, 1 x rear panel)
KVM Ports16 x HDMI Female
16 x USB Type B Female
16 x 3.5mm Audio Jack Female (Green)
Firmware Upgrade1 x RJ11 Female
Power1 x DC Jack
USB Hub2 x USB Type A Female (1 x front panel, 1 x rear panel)
Switches
Port Selection16 x Pushbutton
Reset1 x Semi-recessed Pushbutton
Firmware Upgrade1 x Slide Switch
LEDs
USB Link16 (Green)
Power1 (Dark Green)
On Line /Selected16 (Orange)
Emulation
Keyboard / MouseUSB
Video1920 x 1080 @ 60Hz; 1920 x 1200 @ 60Hz
Scan Interval1 â€“ 255 seconds (default: 5 sec.)
Power ConsumptionDC5V:8.66W:66BTU
Environmental
Operating Temperature0 â€“ 50°C
Storage Temperature-20 â€“ 60°C
Humidity0 â€“ 80% RH, Non-condensing
Physical Properties
HousingMetal
Weight3.86 kg ( 8.5 lb )
Dimensions (L x W x H)43.24 x 25.72 x 4.40 cm
(17.02 x 10.13 x 1.73 in.)
NoteFor some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.


Package Contents

  • 1x 16-Port USB HDMI KVM Switch with Rack Mounting Kit

  • 2x KVM Cable (HDMI, USB, Audio; 1.8m/6ft)

  • 1x Firmware Upgrade Cable

  • 1x Power Adapter

  • 1x Foot Pad Set (4 pcs)

  • 1x User Instructions
