Aten 1 Port KVM Over IP (KN1000)

Aten 1 Port KVM Over IP (KN1000)
  • 50142_thumb_P_1552521882560
  • 50142_thumb_P_1552521900181
  • 50142_thumb_P_1552521900957
or 4x fortnightly payments of $330 with ZipPay
Learn more

Pick Up Time :

Get a $5 credit or a free drink if order not ready on pick up time.


- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

WishAdd to Wishlist

Buy Now, Pay Later:
Buy now with PayPal
   Your Store   Question Mark

Your store is set to:

Check live stock level

Bell  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Pickup.


  • Product Name:
    Aten 1 Port KVM Over IP (KN1000)
  • Model Number:
  • Brand:
  • Manufacturer Warranty:
    2 Year


Aten 1 Port KVM Over IP (KN1000)

  • High video resolution – up to 1600 x 1200 @ 60Hz- 32 bit color depth for the local console; up to 1600 x 1200 @ 60Hzwith 24 bit color depth for remote sessions * Compatible KVM Switches include the following: CS9134, CS9138, CS88A, CS1308, CS1316, CS1754*, CS1758, CS1708A, CS1716A, ACS1208A, ACS1216A, KH2508A, KH2516A, KH1508A, and KH1516A

  • Virtual media enables file applications, OS patching, software installation and diagnostic testing

  • BIOS-level access


Console Ports1 x SPHD-18 Male (Yellow)
KVM Ports1 x SPHD-18 Female (Yellow)
PON1 x DB-9 Male
RS-2321 x DB-9 Male
LAN Ports1 x RJ-45 Female
Power Inlets1 x IEC320 C14
Power Outlets1 x IEC320 C13
Power1 x DC Jack
Virtual Media1 x USB Mini-B Female
Reset1 x Semi-recessed pushbutton
Power1 (Orange)
Power Outlets1 (Orange)
Link1 (Green)
10/100 Mbps1 (Orange/Green)
Keyboard / MouseUSB; PS/2
Video1600 x 1200 @ 60 Hz; DDC2B
Maximum Input Power Rating100–240 V~ 50/60 Hz, 10A
Output100–240 V~; 50/60 Hz; 9A
Power ConsumptionDC5.3V:6.77W:40BTU
Operating Temperature0-40°C
Storage Temperature-20-60°C
Humidity0 - 80% RH, Non-condensing
Physical Properties
Weight0.86 kg ( 1.89 lb )
Dimensions (L x W x H)31.00 x 8.15 x 4.20 cm
(12.2 x 3.21 x 1.65 in.)
NoteFor some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.

Package Contents

  • 1x KN1000 KVM over IP

  • 1x Custom KVM Cable (VGA, USB; 1.2m/4ft)

  • 1x Custom KVM Cable (VGA, PS/2; 1.2m/4ft)

  • 1x Custom Console Cable (VGA, USB, PS/2; 27cm/0.88ft)

  • 1x USB Cable (USB-A to USB Mini-B; 1.8m/6ft)

  • 1x Power Adapter

  • 1x Outlet Power Cord

  • 1x Rack Mount Kit

  • 1x Software CD

  • 1x User Instructions
