CHIPSET

Build in Intel® C621

MEMORY

12 x DIMM, Max. 1536GB, DDR4   2933/2666/2400 MHz RDIMM, LR-DIMM Memory

* Please refer to ASUS AVL for the   latest update.

* Actual memory frequency differs   from Intel CPU types and memory module. Please check Intel official site for   more detail about the memory types supported by each CPU.

GRAPHIC

 Integrated Graphics Processor

VGA port(Optional)

- Supports VGA with max. resolution   1920 x 1200 @ 60 Hz

Aspeed AST2500 with 64 MB VRAM

MULTI GPU SUPPORT

 Supports NVIDIA® 4-Way SLI™ Technology *1

Supports AMD 4-Way CrossFireX Technology *1

EXPANSION SLOTS

 3 x PCIe 3.0 x16 (x16 mode)

2 x PCIe 3.0 x16 (Single at x16, dual at x8/x8)

2 x PCIe 3.0 x16 (x8 mode)

STORAGE

 Intel® C621 Chipset :

8 x SATA 6Gb/s port(s),

Support Raid 0, 1, 5, 10

ASMedia® SATA 6Gb/s controller :

2 x SATA 6Gb/s port(s),

4 x U.2 connector,

1 x M.2 Socket 3, with M Key, type 2242/2260/2280/22110 storage   devices support (both SATA & PCIE mode)

LAN

 Intel® I210-AT, 2 x Gigabit LAN Controller(s)

WIFI

BLUETOOTH

AUDIO

 Realtek® S1220A 7.1-Channel High Definition Audio CODEC *2

- Power pre-regulator reduces power input noise to ensure consistent   performance

- Impedance sense for front and rear headphone outputs

- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking

- High quality SNR stereo playback output and 113 dB SNR recording   input (Line-in)

- Front panel audio connector (AAFP)

- Supports up to 32-Bit/192kHz playback

Audio Feature :

- DTS Connect

- DTS Headphone:X

- Optical S/PDIF out port(s) at back panel

- Premium Japanese audio capacitors: Provide warm, natural and   immersive sound with exceptional clarity and fidelity

- Unique de-pop circuit: Reduces start-up popping noise to audio   outputs

USB PORTS

 ASMedia® USB 3.1 Gen 2 controller :

2 x USB port(s) (2 at back panel, , Type-A + USB Type-CTM)

Intel® C621 Chipset :

8 x USB 3.1 Gen 1 port(s) (4 at back panel, , 4 at mid-board)

Intel® C621 Chipset :

4 x USB 2.0 port(s) (2 at back panel, , 2 at mid-board)

SOFTWARE FEATURES

 ProCool Power Connector

USB BIOS Flashback®

ASUS PIKE SAS upgrade kit*3

ASUS SPL FEATURES

 Gamer's Guardian:

- DIGI+ VRM

- SafeSlot

ASUS Digital Power Design :

- Industry leading Digital 7 + 1 Phase CPU Power Design

- Industry leading Digital 2 Phase DRAM Power Design

ASUS Exclusive Features :

- Front Panel USB 3.0 Support

ASUS Q-Design :

- ASUS Q-Shield

- ASUS Q-Code

- ASUS Q-DIMM

M.2 and U.2 Onboard (The Latest Transfer Technology with up to 32Gb/s   Data-transfer Speeds for M.2 and U.2)

BACK I/O PORTS

 1 x PS/2 keyboard/mouse combo port(s)

2 x LAN (RJ45) port(s)

2 x USB 3.1 Gen 2 *4

4 x USB 3.1 Gen 1

4 x USB 2.0

1 x Optical S/PDIF out

1 x USB BIOS Flashback® Button(s)

1 x 8-channel Audio I/O

IN TERNAL I/O PORTS

2 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 4   USB 3.1 Gen 1 port(s)

1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)

1 x M.2 Socket 3

1 x TPM header

1 x COM port(s) connector(s)

10 x SATA 6Gb/s connector(s)

1 x VROC_HW_Key

2 x CPU Fan connector(s) (2 x 4 -pin)

7 x Chassis Fan connector(s) *5

2 x 8-pin EATX 12 V Power connector

1 x 24-pin EATX Power connector(s)

1 x VGA connector(s)

1 x Front panel audio connector(s) (AAFP)

1 x AUX panel header(s)

1 x SMBus header(s)

1 x 6-pin EATX 12V_3 Power connector

1 x System panel connector

4 x U.2 Connector (support U.2 NVMe device)

FORM FACTOR

 EEB Form Factor

12 inch x 13 inch ( 30.5 cm x 33 cm )
