Chipset

Intel® B660 Chipset

Memory

4 x DIMM, Max. 128GB,   DDR5 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(OC)/   Non-ECC, Un-buffered Memory*

Dual Channel Memory   Architecture

Supports Intel® Extreme   Memory Profile (XMP)

OptiMem II

*Actual Memory data   rate support depends on the CPU types and DRAM modules, for more information   refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).

Graphics

1 x DisplayPort**

1 x HDMI® port***

*Graphics specifications   may vary between CPU types. Please refer to www.intel.com for any updates.

** Support 8K@60Hz as   specified in DisplayPort 1.4.

*** Support 4K@60Hz as   specified in HDMI 2.1.

Expansion Slots

Intel® 12th Gen   Processors

1 x PCIe 5.0 x16   slot(s)

Intel® B660 Chipset

1 x PCIe 3.0 x16 slot   (supports x4 mode)

2x PCIe 4.0 x1 slots

Storage

Total supports 2 x M.2   slots and 4 x SATA 6Gb/s ports

Intel® 12th Gen   Processors

M.2_1 slot (Key M),   type 2242/2260/2280

- Intel® 12th Gen   processors support PCIe 4.0 x4 mode.

Intel® B660 Chipset**

M.2_2 slot (Key M),   type 2242/2260/2280 (supports PCIe 4.0 x4)

4 x SATA 6Gb/s ports

** Intel® Rapid Storage   Technology supports Intel® Optane Memory H Series on PCH attached M.2 slots.

Ethernet

1 x Intel® 2.5Gb   Ethernet

ASUS LANGuard

Wireless & Bluetooth

"Wi-Fi 6

2x2 Wi-Fi 6 (802.11   a/b/g/n/ac/ax)

Supports 2.4/5GHz   frequency band

Bluetooth v5.2"

USB

Rear USB (Total 9   ports)

1 x USB 3.2 Gen 2x2   port(s) (1 x USB Type-C®)

1 x USB 3.2 Gen 2   port(s) (1 x Type-A)

3x USB 3.2 Gen 1   port(s) (2 x Type-A, 1 x USB Type-C®)

4 x USB 2.0 port(s) (4   x Type-A)

Front USB (Total 7   ports)

1 x USB 3.2 Gen 2   connector (supports USB Type-C®)

1 x USB 3.2 Gen 1   header(s) support(s) additional 2 USB 3.2 Gen 1 ports

2 x USB 2.0 header(s)   support(s) additional 4 USB 2.0 ports

Audio

"ROG SupremeFX 7.1   Surround Sound High Definition Audio CODEC S1220A

- Impedance sense for   front and rear headphone outputs

- Supports:   Jack-detection, Multi-streaming, Front Panel Jack-retasking

- High quality 120 dB   SNR stereo playback output and 113 dB SNR recording input

- Supports up to   32-Bit/192 kHz playback"

Audio Features

- SupremeFX Shielding   Technology

- Savitech SV3H712 AMP

- Premium audio   capacitors

- Audio cover

* Due to limitations in   HDA bandwidth, 32-Bit/192 kHz is not supported for 7.1 Surround Sound audio.

Back Panel I/O Ports

1 x USB 3.2 Gen 2x2   port (1 x USB Type-C®)

1 x USB 3.2 Gen 2 port   (1 x Type-A)

3 x USB 3.2 Gen 1   port(s) (2 x Type-A, 1 x USB Type-C®)

4 x USB 2.0 port(s) (4   x Type-A)

1 x DisplayPort

1 x HDMI® port

1 x Wi-Fi Module

1 x Intel® 2.5Gb   Ethernet port

5 x Audio jacks

1 x BIOS FlashBack™   button

Internal I/O Connectors

Fan and Cooling related

1 x 4-pin CPU Fan   header(s)

1 x 4-pin AIO Pump   header(s)

2 x 4-pin Chassis Fan   header(s)

Power related

1 x 24-pin Main Power   connector

1 x 8-pin +12V Power   connector

Storage related

2 x M.2 slots (Key M)

4 x SATA 6Gb/s ports

USB

1 x USB 3.2 Gen 2 connector   (support(s) USB Type-C®)

1 x USB 3.2 Gen 1   header(s) support(s) additional 2 USB 3.2 Gen 1 ports

2 x USB 2.0 header(s)   support(s) additional 4 USB 2.0 ports

Miscellaneous

3 x Addressable Gen 2   header(s)

1 x AURA RGB header(s)

1 x Clear CMOS header

1 x COM Port header

1 x Front Panel Audio   header (AAFP)

1 x S/PDIF Out header

1 x SPI TPM header   (14-1pin)

1 x 20-3 pin System   Panel header with Chassis intrude function

1 x Thermal Sensor   header

1 x Thunderbolt™ header

Special Features

Extreme Engine Digi+

- 5K Black Metallic   Capacitors

ASUS Q-Design

- M.2 Q-Latch

- Q-DIMM

- Q-LED (CPU [red],   DRAM [yellow], VGA [white], Boot Device [yellow green])

- Q-Slot

ASUS Thermal Solution

- M.2 heatsink

ASUS EZ DIY

- BIOS FlashBack™   button

- BIOS FlashBack™ LED

- CPU Socket lever   protector

- ProCool

- Pre-mounted I/O   shield

- SafeSlot

- SafeDIMM

AURA Sync

- AURA RGB header(s)

- Addressable Gen 2   header(s)

Software Features

ROG Exclusive Software

- GameFirst VI

- ROG CPU-Z

- Sonic Studio III +   Sonic Studio Virtual Mixer + Sonic Suite Companion

- Sonic Radar III

- DTS® Sound Unbound

- Anti-virus software

ASUS Exclusive Software

Armoury Crate

- AIDA64 Extreme (60   days free trial)

- AURA Creator

- AURA Sync

- Fan Xpert 4

- Two-Way AI Noise   Cancelation

AI Suite 3

- Performance And Power   Saving Utility

TPU

EPU

DIGI+ VRM

MyAsus

WinRAR

UEFI BIOS

AI Overclocking Guide

ASUS EZ DIY

- ASUS CrashFree BIOS 3

- ASUS EZ Flash 3

- ASUS UEFI BIOS EZ   Mode

MemTest86

BIOS

256 Mb Flash ROM, UEFI   AMI BIOS

Manageability

WOL by PME, PXE

Accessories

Cables

2 x SATA 6Gb/s cables

Miscellaneous

1 x ASUS Wi-Fi moving   antennas

1 x Cable ties pack

1 x M.2 Rubber   Package(s)

1 x M.2 Q-Latch   package(s)

1 x ROG key chain

1 x ROG Strix stickers

1 x ROG Strix thank you   card

Installation Media

1 x Support DVD

Documentation

1 x User guide

Operating System

Windows® 11 64-bit,   Windows® 10 64-bit

Form Factor

mATX Form Factor

9.6 inch x 9.6 inch (   24.4 cm x 24.4 cm )
