CHIPSET

MEMORY

4 x DIMM, Max. 128GB, DDR4 2666/2400/2133 MHz ECC and non-ECC Memory

Dual Channel Memory Architecture

Supports Intel® Extreme Memory Profile (XMP)

ECC Memory (ECC mode) support varies by CPU.

* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).

* The maximum memory frequency supported varies by processor

** DDR4 2666MHz and higher memory modules will run at max. 2666MHz on Intel® 8th Gen. 6-core or higher processors.

GRAPHIC

Integrated Graphics Processor- Intel® UHD Graphics support

Multi-VGA output support : HDMI/DisplayPort ports

- Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz

- Supports DisplayPort 1.2 with max. resolution 4096 x 2160 @ 60 Hz

Maximum shared memory of 2048 MB (for iGPU exclusively)

MULTI GPU SUPPORT

EXPANSION SLOTS

2 x PCIe 3.0/2.0 x16 (x16 or dual x8)

1 x PCIe 3.0/2.0 x16 (max at x2 mode)

2 x PCIe 3.0/2.0 x1

STORAGE

Intel® C246 Chipset :

1 x M.2_1 socket 3, , with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)

1 x M.2_2 socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 2 mode)

1 x U.2 connector*2

4 x SATA 6Gb/s port(s)

Support Raid 0, 1, 5, 10

Intel® Rapid Storage Technology supports

LAN

Intel® I210-AT, 1 x Gigabit LAN Controller(s)

Intel® I219-LM , 1 x Gigabit LAN Controller(s)

ASUS Turbo LAN Utility

ASUS LAN Guard

WIFI

BLUETOOTH

AUDIO

Realtek® ALC S1220A 8-Channel High Definition Audio CODEC featuring Crystal Sound 3

- Power pre-regulator reduces power input noise to ensure consistent performance

- Impedance sense for front and rear headphone outputs

- Internal audio Amplifier to enhance the highest quality sound for headphone and speakers

- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, Front Panel MIC Jack-retasking

Audio Feature :

- Optical S/PDIF out port(s) at back panel

- Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference

- Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals

- Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity

- Unique de-pop circuit: Reduces start-up popping noise to audio outputs

USB PORTS

Intel® C246 Chipset :

4 x USB 3.2 Gen 2 port(s) (4 at back panel, , 3 x Type-A, 2 at mid-board)

Intel® C246 Chipset :

6 x USB 2.0 port(s)

Intel® C246 Chipset :

4 x USB 2.0 port(s) (4 at mid-board)

SOFTWARE FEATURES

ASUS SPL FEATURES

ASUS 5X Protection III :

- ASUS SafeSlot Core: Fortified PCIe Slot prevents damage

- ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!

- ASUS Enhanced DRAM Overcurrent Protection - Short circuit damage prevention

- ASUS ESD Guards - Enhanced ESD protection

ASUS EPU :

- EPU

ASUS Exclusive Features :

- AI Suite 3

- Ai Charger

- Turbo LAN

- Armoury Crate

- ASUS NODE: hardware control interface

ASUS Quiet Thermal Solution :

- Stylish Fanless Design Heat-sink solution & MOS Heatsink

- ASUS Fan Xpert 4

ASUS EZ DIY :

- ASUS CrashFree BIOS 3

- ASUS EZ Flash 3

- ASUS UEFI BIOS EZ Mode

ASUS Q-Design :

- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)

- ASUS Q-Slot

- ASUS Q-DIMM

M.2 and U.2 Onboard (The Latest Transfer Technology with up to 32Gb/s Data-transfer Speeds for M.2 and U.2)

BACK I/O PORTS

1 x DisplayPort

1 x HDMI

2 x LAN (RJ45) port(s)

3 x USB 3.1 Gen 2 (teal blue)Type-A,

1 x USB 3.1 Gen 2 Type-C

4 x USB 3.1 Gen 1 (blue)

1 x Optical S/PDIF out

5 x Audio jack(s)

IN TERNAL I/O PORTS

1 x AAFP connector

1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin)

2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)

1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)

1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage devices support (both SATA & x2 PCIE mode)

4 x SATA 6Gb/s connector(s)

1 x CPU Fan connector(s)

1 x CPU OPT Fan connector(s)

3 x Chassis Fan connector(s) ()

1 x 24-pin EATX Power connector(s)

2 x 8-pin ATX 12V Power connector(s)

1 x Thermal sensor connector(s)

1 x Clear CMOS jumper(s)

1 x Node Connector(s)

1 x U.2 connector

1 x System panel connector

1 x COM port header

1 x AIO PUMP Header

ACCESSORIES

User's manual

I/O Shield

1 x M.2 Screw Package

1 x Supporting DVD

BIOS

MANAGEABILITY

OS

FORM FACTOR

ATX Form Factor

12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
