Asus Prime H310M-E R2.0 LGA 1151 mATX Motherboard (Prime H310M-E R2.0)

Asus Prime H310M-E R2.0 LGA 1151 mATX Motherboard (Prime H310M-E R2.0)
  • 49917_thumb_P_1551071934683
  • 49917_thumb_P_1551071973299
  • 49917_thumb_P_1551071974846
$89.0
or 4x fortnightly payments of $330 with ZipPay
Learn more

Pick Up Time :

Delivery:

- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

WishAdd to Wishlist

Buy Now, Pay Later:
Buy now with PayPal
   Your Store   Question Mark

Your store is set to:

Check live stock level

Bell  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Pickup.

Specifications

  • Product Name:
    Asus Prime H310M-E R2.0 LGA 1151 mATX Motherboard (Prime H310M-E R2.0)
  • Model Number:
    Prime H310M-E R2.0
  • Brand:
  • Manufacturer Warranty:
    3 Year

Description

Asus Prime H310M-E R2.0 LGA 1151 mATX Motherboard


  • ASUS OptiMem: Careful routing of traces and vias to preserve signal integrity for improved memory stability.

  • Fan Xpert: Flexible controls for ultimate cooling and quietness, plus GPU-temperature sensing for cooler gaming.

  • 5X Protection III: Multiple hardware safeguards for all-round protection.



Asus Prime H310M-E R2.0 LGA 1151 mATX Motherboard (Prime H310M-E R2.0)


Specifications


CPU

IntelĀ® Socket 1151 for 8th Generation Coreā„¢   i7/Coreā„¢ i5/Coreā„¢ i3/PentiumĀ®/CeleronĀ® Processors
  Supports IntelĀ® 14 nm CPU
  Supports IntelĀ® Turbo Boost Technology 2.0
  * The IntelĀ® Turbo Boost Technology 2.0 support depends on the CPU types.
  * Refer to www.asus.com for   CPU support list

Chipset

IntelĀ® H310

Memory

2 x DIMM, Max. 32GB, DDR4   2666/2400/2133 MHz Non-ECC, Un-buffered Memory
  Dual Channel Memory Architecture
  Supports IntelĀ® Extreme Memory Profile (XMP)
  * Refer to www.asus.com for   the Memory QVL (Qualified Vendors Lists).
  * The maximum memory frequency supported varies by processor
  ** DDR4 2666MHz and higher memory modules will run at max. 2666MHz on IntelĀ®   8th Gen. 6-core or higher processors.

Graphic

Integrated Graphics Processor-   IntelĀ® HD Graphics support
  Multi-VGA output support : HDMI/D-Sub ports
  - Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz / 25600 x 1600   @ 60 Hz
  - Supports D-sub with max. resolution 1920 x 1200 @ 60 Hz
  Maximum shared memory of 1024 MB (for iGPU exclusively)
  Supports IntelĀ® InTruā„¢ 3D, Quick Sync Video, Clear Video HD Technology,   Insiderā„¢

Expansion   Slots

1 x PCIe 3.0/2.0 x16 (x16 mode,   gray)
  2 x PCIe 2.0 x1

Storage

IntelĀ® H310 Chipset :
  1 x M.2 Socket 3, , with M Key, type 2242/2260/2280 storage devices support   (both SATA & x2 PCIE mode)*1
  4 x SATA 6Gb/s port(s), gray,

LAN

RealtekĀ® RTL8111H, 1 x Gigabit   LAN

Audio

RealtekĀ® ALC887 8-Channel High   Definition Audio CODEC
  - Supports : Jack-detection, Front Panel Jack-retasking
  Audio   Feature :
  - LED-illuminated design - Brighten up your build with the gorgeous   illuminated audio trace path.
  - Audio Shielding: Ensures precision analog/digital separation and greatly   reduced multi-lateral interference
  - Dedicated audio PCB layers: Separate layers for left and right channels to   guard the quality of the sensitive audio signals
  - Premium Japanese audio capacitors: Provide warm, natural and immersive   sound with exceptional clarity and fidelity
  * Choose the chassis with HD audio module in front panel to support 8-channel   audio output.

USB Ports

IntelĀ® H310 Chipset :
  4 x USB 3.1 Gen 1 up to 5Gbps port(s) (2 at back panel, blue, Type-A, 2 at   mid-board)
  IntelĀ® H310 Chipset :
  6 x USB 2.0/1.1 port(s) (2 at back panel, , 4 at mid-board)

Special Features

ASUS 5X Protection III :
  - ASUS SafeSlot Core: Fortified PCIe Slot prevents damage
  - ASUS LANGuard: Protects against LAN surges, lightning strikes and   static-electricity discharges!
  - ASUS Overvoltage Protection: World-class circuit-protecting power design
  - ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater   durability!
  - ASUS DIGI+ VRM: 4 Phase digital power design
  ASUS OptiMem
ļ¼š
  - Optimem (Improved DDR4 stability)
  ASUS EPU :
  - EPU
  ASUS Exclusive Features :
  - AI Suite 3
  - Ai Charger
  - PC Cleaner
  - File Transfer
  ASUS Quiet Thermal Solution :
  - Stylish Fanless Design Heat-sink solution
  - ASUS Fan Xpert
  ASUS EZ DIY :
  - ASUS CrashFree BIOS 3
  - ASUS EZ Flash 3
  - ASUS UEFI BIOS EZ Mode
  ASUS Q-Design :
  - ASUS Q-DIMM
  M.2 Onboard(The latest transfer technologies with up to 10Gb/s   data transfer speeds)

Back I/O Ports

1 x PS/2 keyboard (purple)
  1 x PS/2 mouse (green)
  1 x D-Sub
  1 x HDMI
  1 x LAN (RJ45) port(s)
  2 x USB 3.1 Gen 1 (blue) Type-A, up to 5Gbps
  2 x USB 2.0
  3 x Audio jack(s)

Internal   I/O Ports

1 x USB 3.1 Gen 1(up to 5Gbps)   connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin)
  2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
  1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support   (both SATA & x2 PCIE mode)
  1 x TPM header
  1 x COM port(s) connector(s)
  4 x SATA 6Gb/s connector(s)
  1 x CPU Fan connector(s) (1 x 4 -pin)
  1 x Chassis Fan connector(s) (1 x 4 -pin)
  1 x S/PDIF out header(s)
  1 x 24-pin EATX Power connector(s)
  1 x 4-pin ATX 12V Power connector(s)
  1 x Front panel audio connector(s) (AAFP)
  1 x Clear CMOS jumper(s)
  1 x System panel connector
  1 x Speaker connector

Accessories

User's manual
  I/O Shield
  2 x SATA 6Gb/s cable(s)
  1 x M.2 Anchor
  1 x Supporting DVD

BIOS

128 Mb Flash ROM, UEFI AMI   BIOS, PnP, SM BIOS 3.1, ACPI 6.1, MultilanguageBIOS, ASUS EZ Flash 3,   CrashFree BIOS 3, F6 Qfan Control, F3 MyFavorites, Last Modified log, F12   PrintScreen, and ASUS DRAM SPD (SerialPresence Detect) memory information

Manageability

WOL by PME, PXE

Operating System

WindowsĀ® 10 64-bit

Form   Factor

mATX Form Factor

8.9 inch x 7.3 inch ( 22.6 cm x   18.5 cm )

Note

*1 When a device in SATA mode   is installed on the M.2 socket, SATA_2 port cannot be used.
  Due to the Chipset limitation, when a M.2 device is installed in PCIe mode,   the socket is set
  to PCIe 2.0.


All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets.

Specifications and features vary by model, and all images are illustrative. Please refer specification pages for full details.

PCB color and bundled software versions are subject to change without notice.

Brand and product names mentioned are trademarks of their respective companies.
