SPECIFICATIONS:
WIRELESS
Working Modes
Range Extender/Access Point
HARDWARE FEATURES
Plug Type
AU
Standards and Protocols
IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.11a
Interface
1x 10/100/1000M Ethernet Port (RJ45)
Ports
1 Gigabit Ethernet Port
Button
WPS Button, Reset Button, LED Button, Power Button
Input Power
100-240V~50/60Hz
Power Consumption
12W（max power consumption）
Dimensions ( W x D x H )
6.4x 3.4 x 1.6 in. (163 x 86 x 40mm)
Antenna
4x external
WIRELESS FEATURES
Wireless Standards
IEEE 802.11a/n/ac 5GHz, IEEE 802.11b/g/n 2.4GHz
Frequency
2.4GHz & 5GHz(11ac)
Signal Rate
5GHz:Up to 1733Mbps
2.4GHz:Up to 800Mpbs
Reception Sensitivity
5GHz：
11a 6Mbps:-96dBm@10% PER
11a 54Mbps: -78dBm@10% PER
11ac HT20 mcs8: -69dBm@10% PER
11ac HT40 mcs9: -66dBm@10% PER
11ac HT80 mcs9: -63dBm@10% PER
2.4GHz:
11g 54M: -79dBm@10% PER
11n HT20 mcs7: -77dBm@10% PER
11n HT40 mcs7: -74dBm@10% PER
Wireless Modes
Wireless Functions
Wireless Statistic
Concurrent Mode boost both 2.4G/5G WiFi band
High Speed Mode for great speed for HD Gaming and video
Access Control
LED Control
Domain Login Function
Wireless Security
64/128-bit WEP
WPA-PSK / WPA2-PSK
Transmission Power
<20dBm(2.4GHz)
<23dBm(5GHz)
OTHERS
Certification
FCC, RoHS
Package Contents
AC2600 Wi-Fi Range Extender RE650
Quick Installation Guide
Box Dimensions (W X D X H)
7.9 x 4.9 x 3.8in. (202x 125 x 97mm)
System Requirements
Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® or Linux.
Environment
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
