Swan M20W Powered 2.1 System Speakers

Swan M20W Powered 2.1 System Speakers
  • 33058
$261.5
or 4x fortnightly payments of $330 with ZipPay
Learn more

Pick Up Time :

Get a $5 credit or a free drink if order not ready on pick up time.

Delivery:

- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

WishAdd to Wishlist

Buy Now, Pay Later:
Buy now with PayPal
   Your Store   Question Mark

Your store is set to:

Check live stock level

Bell  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Pickup.

Specifications

  • Product Name:
    Swan M20W Powered 2.1 System Speakers
  • Model Number:
    HiVi M-20W
  • Brand:
  • Manufacturer Warranty:
    1 Year

Description





High end 2.1 multimedia sound system with classic styling and wood cabinets.

     When we first looked at getting into the multi media speaker market we looked at what was available from other manufactures. What we found were cheap drivers housed in plastic boxes driven by inexpensive amplifiers. The boomy subwoofer masked the anemic sound of the satellites. Turn the subwoofer off and you got the true picture.

     So we decided to build multimedia speakers using wood cabinets, high quality drivers and a decent amplifier. The M20 uses a response 3"driver and a 6"subwoofer in wood cabinets. Wood is much more effective dampening back wave transmission than plastic. The amplifier doesn't skimp on parts. The result is a surprising quality of sound for the price. The volume control is located on light cord that extends from the speaker making allowing you to make adjustments easily at any time.






General DataModel HiVi M-20W
   System Series HiVi Satellite 2.1 multimedia speaker system
HiVi M-20W Satellite:HiVi M-20S
Acoustic SystemSystem Type 1-way sealed-box full range satellite system
   Drivers Configuration Woofer:M3N
   Frequency Range 118Hz-20kHz(-6dB)
   Horizontal Dispersion 15deg < 250Hz-8000Hz < ±4dB
   Harmonic Distortion 300Hz-20kHz‰1%(2.83V/1m)
   Vertical Dispersion 5deg < 250Hz-8000Hz < ±4dB
   Sensitivity 83dB (2.83V/1m)
   Nominal Impedance 8¦
   Power Range 10-20 W
Other ParameterFinished Walnut/piano lacquer
   Dimension (W x H x D) 126 x 125 x 116
   Net Weight 1.2kg
HiVi M-20W SUB
Acoustic SystemSystem Series Hi Vi Multimedia Series
   System Type Active 1-way sealed-box sub system
   Drivers Configuration WooferBG6N
   Frequency Range 50Hz-180Hz (-6dB)
   Harmonic Distortion THD<0.1% ( 8¦100Hz30W )
   Sensitivity 88dB (2.83V/1m)
   Nominal Impedance 8¦
   Power Range 10-40 W
Other ParameterFinished Walnut/piano lacquer
   Dimension (W x H x D) 234 x 257 x 227
   Net Weight 7.5 Kg
Left/Right Satellite box
Amplifiers SystemRated Power 15W x 2 RMS
   Frequency Range 120Hz~20kHz(0.5dB)Rated
   Separation >70dBˆLR‰
   Signal-to-Noise >90dB
   Distortion THD<0.08% ( 8¦100Hz30W )
   Input sensitivity 500mV
   Input impedance 22k¦
Powered subwoofer
Amplifiers SystemRated Power 50W RMS
   Frequency Range 20HZ-120Hz
   Signal-to-Noise >85dB
   Distortion THD<0.1% ( 8¦100Hz30W )
   Input sensitivity 200mV
   Input impedance 22k¦


* Specifications are subject to change without notice.
  * Specifications may vary.
  * The product picture(s) is only for your reference, it may differ from the actual product.
