Specifications

  • Product Name:
    SilverStone StridePlus ST65F-PB 650W Power Supply Bronze Modular
  • Model Number:
    ST65F-PB
  • Brand:
  • Manufacturer Warranty:
    3 Year

Description

SilverStone StridePlus ST65F-PB 650W Power Supply Bronze Modular


  • High efficiency with 80 PLUS Bronze certification

  • 24/7 continuous power output with 40℃ operating temperature

  • 100% modular cables with flexible flat arrays

  • Class-leading single +12V rail

  • Strict ±3% voltage regulation and low ripple & noise

  • Silent running 120mm fan with 18dBA

  • PCIe 8/6pin connectors support


SilverStone StridePlus ST65F-PB 650W Power Supply Bronze Modular


Specifications


MAX. DC OUTPUT

650W

POWER DENSITY

360W per litre

COLOR

BlackLead-Free   Paint

COMBINED +3.3V &   +5V

100W

COMBINED +12V

610W

INPUT VOLTAGE

103 ~ 264 Vrms

INPUT FREQUENCY RANGE

47Hz~63Hz

PFC

Active PFCPF>0.9   at full load

EFFICIENCY

82%~85% at 20% ~ 100%   loading

MTBF

100,000 hours

OPERATING TEMPERATURE

0°C ~ 40°C

PROTECTION

Over power protection
  Over current protection
  Over voltage protection
  Over Temperature Protection
  Under voltage protection
  Short circuit protection

CONNECTORS

1 x 24 / 20-Pin motherboard   connector600mm
  1 x 8 / 4-Pin EPS / ATX 12V connector
750mm
  2 x 8/6-P in PCIe connector
550mm   / 150mm
  8 x SATA connector
"600mm / 150mm /   150mm / 150mm" x 2
  3 x 4-Pin peripheral connector
600mm   / 150mm / 150mm
  1 x 4-Pin floppy connector
150mm

COOLING SYSTEM

Single 120mm silent fan

FORM FACTOR

ATX

NOISE LEVEL

18 dBA minimum

DIMENSION

150 mm (W) x 86 mm (H) x 140   mm (D)
  5.91" (W) x 3.39" (H) x 5.51" (D)

WEIGHT

1.48 kg

CERTIFICATION

80 PLUS Bronze

OTHER

GPU Support list
  Compatible with ATX12V v2.4

  • Specifications presented on this page contains most recent revisions and may differ from those printed on retail boxes or manuals.



Load Range:


+3.3V

+5V

+12V

+5VSB

-12V

MAX.(AMPS)

18A

18A

50.8A

2.5A

0.3A

PEAK (AMPS)

/

/

/

/

/

MIN.(AMPS)

0A

0.2A

0.1A

0A

0A

RANGE (%)

±3%

±3%

±3%

±5%

±10%

LINE REG.(%)

±1%

±1%

±1%

±1%

±1%

RIPPLE(MVP-P)

50mV

50mV

80mV

50mV

100mV
