Chipset

AMD X570

Memory

AMD Ryzen™ 5000 Series   processors:

Support for DDR4   4866(O.C.) / 4600(O.C.)/ 4400(O.C.) / 4300(O.C.) / 4266(O.C.) / 4133(O.C.) /   4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) /   3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz   memory modules

AMD Ryzen™ 4000   G-Series processors:

Support for DDR4   5100(O.C.) / 5000(O.C.) / 4866(O.C.) / 4600(O.C.)/ 4400(O.C.) / 4300(O.C.) /   4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) /   3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933   / 2667 / 2400 / 2133 MHz memory modules

AMD Ryzen™ 3000 Series   processors:

Support for DDR4   4600(O.C.)/ 4400(O.C.) / 4300(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) /   3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) /   3333(O.C.) / 3300(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules

AMD Ryzen™ 3000   G-Series Processors/AMD Ryzen™ 2000 Series Processors/ AMD Ryzen™ 2000   G-Series Processors:

Support for DDR4   3200(O.C.) / 2933 / 2667 / 2400 / 2133 MHz memory modules

4 x DDR4 DIMM sockets   supporting up to 128 GB (32 GB single DIMM capacity) of system memory

Dual channel memory   architecture

Support for ECC   Un-buffered DIMM 1Rx8/2Rx8 memory modules

Support for non-ECC   Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

Support for Extreme   Memory Profile (XMP) memory modules

(Please refer   "Memory Support List" for more information.)

Onboard Graphics

Integrated Graphics   Processor:

1 x HDMI port,   supporting a maximum resolution of 4096x2160@60 Hz

* Support for HDMI 2.1   version, HDCP 2.3, and HDR.

Maximum shared memory   of 16 GB

(Note) For AMD Ryzen™   4000 G-Series Processors/AMD Ryzen™ 3000 G-Series Processors/AMD Ryzen™ 2000   G-Series Processors only.

Audio

Realtek® Audio CODEC

High Definition Audio

2/4/5.1/7.1-channel

LAN

Realtek® 2.5GbE LAN   chip (2.5 Gbps/1 Gbps/100 Mbps)

Expansion Slots

1 x PCI Express x16   slot (PCIEX16), integrated in the CPU:

AMD Ryzen™ 5000 Series   Processors/AMD Ryzen™ 3000 Series Processors support PCIe 4.0 x16 mode

AMD Ryzen™ 4000   G-Series Processors/AMD Ryzen™ 2000 Series Processors support PCIe 3.0 x16   mode

AMD Ryzen™ 3000   G-Series Processors/AMD Ryzen™ 2000 G-Series Processors support PCIe 3.0 x8   mode

* For optimum   performance, if only one PCI Express graphics card is to be installed, be   sure to install it in the PCIEX16 slot.

1 x PCI Express x16   slot (PCIEX2), integrated in the Chipset:

Supporting PCIe   4.0(Note)/3.0 x2 mode

* The PCIEX2 slot   shares bandwidth with the SATA3 4, 5 connectors. The SATA3 4, 5 connectors   will become unavailable when a device is installed in the PCIEX2 slot.

2 x PCI Express x1 slots   (PCIEX1_1/PCIEX1_2), integrated in the Chipset:

Supporting PCIe   4.0(Note)/3.0

(Note) For AMD Ryzen™   5000 Series Processors/AMD Ryzen™ 3000 Series Processors only.

Storage Interface

1 x M.2 connector   (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2242/2260/2280/22110   SSDs:

AMD Ryzen™ 5000 Series   Processors/AMD Ryzen™ 3000 Series Processors support SATA and PCIe 4.0 x4/x2   SSDs

AMD Ryzen™ 4000   G-Series Processors/AMD Ryzen™ 3000 G-Series Processors/AMD Ryzen™ 2000   Series Processors/AMD Ryzen™ 2000 G-Series Processors support SATA and PCIe   3.0 x4/x2 SSDs

1 x M.2 connector   (M2C_SB), integrated in the Chipset, supporting Socket 3, M key, type   2242/2260/2280/22110 SSDs:

Supporting PCIe   4.0(Note)/3.0 x4/x2 SSDs

1 x M.2 connector   (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type   2242/2260/2280/22110 SSDs:

Supporting SATA and   PCIe 4.0(Note)/3.0 x4/x2 SSDs

6 x SATA 6Gb/s   connectors, integrated in the Chipset:

Support for RAID 0,   RAID 1, and RAID 10

(Note) For AMD Ryzen™   5000 Series Processors/AMD Ryzen™ 3000 Series Processors only.

USB

CPU:

4 x USB 3.2 Gen 1 ports   on the back panel

Chipset:

2 x USB Type-C® ports,   with USB 3.2 Gen 2 support (1 port on the back panel, 1 port available   through the internal USB header)

1 x USB 3.2 Gen 2   Type-A port (red) on the back panel

2 x USB 3.2 Gen 1 ports   available through the internal USB header

6 x USB 2.0/1.1 ports   (2 ports on the back panel, 4 ports available through the internal USB   headers)

Internal I/O Connectors

1 x 24-pin ATX main   power connector

1 x 8-pin ATX 12V power   connector

1 x CPU fan header

1 x water cooling CPU   fan header

3 x system fan headers

1 x system fan/water   cooling pump header

2 x addressable LED   strip headers

2 x RGB LED strip   headers

1 x CPU cooler LED   strip/RGB LED strip header

3 x M.2 Socket 3   connectors

6 x SATA 6Gb/s   connectors

1 x front panel header

1 x front panel audio   header

1 x USB Type-C® header,   with USB 3.2 Gen 2 support

1 x USB 3.2 Gen 1   header

2 x USB 2.0/1.1 headers

1 x Trusted Platform   Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)

1 x Clear CMOS jumper

＊All fan headers are subject to support   AIO_Pump, Pump and high performance fan with the capability of delivering up   to 2A/12V @ 24W.

Back Panel Connectors

1 x PS/2 keyboard/mouse   port

1 x HDMI port

4 x USB 3.2 Gen 1 ports

2 x USB 2.0/1.1 ports

1 x USB Type-C® port,   with USB 3.2 Gen 2 support

1 x USB 3.2 Gen 2   Type-A port (red)

1 x Q-Flash Plus button

1 x RJ-45 port

6 x audio jacks

I/O Controller

iTE® I/O Controller   Chip

H/W Monitoring

Voltage detection

Temperature detection

Fan speed detection

Water cooling flow rate   detection

Fan fail warning

Fan speed control

* Whether the fan   (pump) speed control function is supported will depend on the fan (pump) you   install.

BIOS

1 x 256 Mbit flash

Use of licensed AMI   UEFI BIOS

PnP 1.0a, DMI 2.7, WfM   2.0, SM BIOS 2.7, ACPI 5.0

Unique Features

Support for APP Center

* Available   applications in APP Center may vary by motherboard model. Supported functions   of each application may also vary depending on motherboard specifications.

@BIOS

EasyTune

Fast Boot

Game Boost

ON/OFF Charge

RGB Fusion

Smart Backup

System Information   Viewer

Support for Q-Flash   Plus

Support for Q-Flash

Support for Xpress   Install

Bundled Software

Norton® Internet   Security (OEM version)

Realtek® 8125 Gaming   LAN Bandwidth Control Utility

Operating System

Support for Windows 10   64-bit

Form Factor

ATX Form Factor; 30.5cm   x 24.4cm

Remark

Due to different Linux   support condition provided by chipset vendors, please download Linux driver   from chipset vendors' website or 3rd party website.

Most hardware/software   vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers   are available from the vendors, we will update them on the GIGABYTE website.
