Asus AC2900 RT-AC86U Dual Band Gigabit WiFi Gaming Router
Ultimate gaming experience - Built-in WTFast® game accelerator and Adaptive QoS deliver lag-free online gaming and smooth 4K UHD streaming Ultrafast Wi-Fi - AC2900 W-Fi speeds boosted with NitroQAM™ and 5GHz quad-stream technology to handle even the busiest home networks with ease Ultrawide Coverage – High-performance antennas, ASUS AiRadar and Range Boost eliminate dead spots, and MU-MIMO maximizes Multi-device performance Ultrapowerful Processor – Enjoy smoother networking and faster data transfers with the PC-grade 1.8GHz 64bit dual-core processor Commercial-grade Security – AiProtection, powered by Trend Micro™, blocks and neutralizes internet security threats for all your connected smart devices AiMesh Supported - Connect your RT-AC86U to other compatible ASUS routers to create a powerful and flexible whole-home Wi-Fi network
Specifications
NETWORK STANDARD | IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IPv4, IPv6 | PRODUCT SEGMENT | AC2900 ultimate AC performance: 750+2167 Mbps | COVERAGE | Large homes | DATA RATE | 802.11a : 6,9,12,18,24,36,48,54 Mbps 802.11b : 1, 2, 5.5, 11 Mbps 802.11g : 6,9,12,18,24,36,48,54 Mbps 802.11n : up to 450 Mbps 802.11ac : up to 1734 Mbps 1024QAM (2.4GHz) : up to 750 Mbps 1024QAM (5GHz) : up to2167 Mbps | ANTENNA | External detachable antenna x 3 Internal antenna x 1 | TRANSMIT/RECEIVE | MIMO technology 2.4 GHz 3 x 3 5 GHz 4 x 4 | PROCESSOR | 1.8 GHz dual-core processor | MEMORY | 256 MB Flash
512 MB RAM | WIFI TECHNOLOGY | Beamforming: standard-based and universal 1024-QAM high data rate 20/40/80 MHz bandwidth | OPERATING FREQUENCY | 2.4 GHz / 5 GHz | ENCRYPTION | 64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK, WPA-Enterprise , WPA2-Enterprise , WPS support | FIREWALL & ACCESS CONTROL | Access control：Parental control, Network service filter, URL filter, Port filter | MANAGEMENT | UPnP, IGMP v1/v2/v3, DNS Proxy, DHCP, NTP Client, DDNS, Port Trigger, Port Forwarding, DMZ, System Event Log | VPN SUPPORT | IPSec Pass-Through PPTP Pass-Through L2TP Pass-Through PPTP server OpenVPN server PPTP client L2TP client OpenVPN client | WAN CONNECTION TYPE | Internet connection type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP | UTILITIES | Router setup wizard; Firmware restoration; Device discovery; printer setup utility | PORTS | RJ45 for Gigabits BaseT for WAN x 1, RJ45 for 10/100/1000/Gigabits BaseT for LAN x 4 USB 2.0 x 1 USB 3.0 x 1 | FEATURES | MU-MIMO Traffic Analyzer Adaptive QoS WTFast Gamers Private Network AiProtection Parental Control Guest Network : 2.4 GHz x 3, 5 GHz x 3 Mac OS Backup Enhanced media server (AiPlayer app compatible) - Image : Jpeg - Audio : mp3, wma, wav, pcm, mp4, lpcm, ogg - Video : asf, avi, divx, mpeg, mpg, ts, vob, wmv, mkv, mov AiCloud personal cloud service 3G/4G data sharing Printer Server - Multifunctional printer support (Windows only) - LPR protocol support Download Master - Support bt, nzb, http, ed2k - Support encryption, DHT, PEX and magnet link - Upload and download bandwidth control - Download scheduling AiDisk file server - Samba and FTP server with account management IPTV support Roaming Assist | BUTTON | WPS Button, Reset Button, Power Button, Wireless on/off Button, LED on/off Button | LED INDICATOR | Power x 1 Wi-Fi x 2 WAN x 1 WPS x 1 LAN x 4 | POWER SUPPLY | AC Input : 110V~240V(50~60Hz) DC Output : 19 V with max. 1.75 A current | OS SUPPORT | Windows® 10 Windows® 8 Windows® 7 Mac OS X 10.6 Mac OS X 10.7 Mac OS X 10.8 Linux | DIMENSIONS | 220 x 160 x 83.3 ~ mm (WxHxD) (Without Bezel) | WEIGHT | 872 g | OPERATION MODE | Wireless router mode Access point mode Media bridge mode |
All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets. Specifications and features vary by model, and all images are illustrative. Please refer to specification pages for full details. PCB color and bundled software versions are subject to change without notice. Brand and product names mentioned are trademarks of their respective companies.
|
